What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is GGNTKT.
-
Format of the data is
a scanned image
.
-
-3dB (resp. -6db) point v.s. reference is at 33.8Hz (resp. 31.3Hz).
-
Reference level is normalised to 0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.5dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 6.99
and would be 8.35 with a
perfect subwoofer.
- Details:
NBD: ON 0.24,
LW 0.256, SP
0.314, PIR
0.269; SM:
SP0.879,
PIR0.895; LFQ
0.851, LFX 30Hz
- Tonality (Preference) Score is 7.51
with an EQ and would be 8.82 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.176,
LW 0.176, SP
0.255, PIR
0.192; SM:
SP0.911,
PIR0.929; LFQ 0.851, LFX 29Hz
-
Link to original Review: asr review.
Links to other reviews: ggntkt review
.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.4dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
33.0 |
0.6 |
2.97 |
| PK |
60.0 |
1.4 |
-2.2 |
| PK |
93.0 |
0.6 |
-0.93 |
| PK |
280.0 |
2.17 |
-1.53 |
| PK |
494.0 |
2.33 |
-0.43 |
| PK |
1103.0 |
1.54 |
0.85 |
| PK |
2909.0 |
2.98 |
1.72 |
| PK |
5310.0 |
1.24 |
0.3 |
| LS |
12662.0 |
0.51 |
0.05 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.5dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
-0.25 |
| PK |
63.0 |
2.14 |
-0.5 |
| PK |
100.0 |
2.14 |
-0.5 |
| PK |
160.0 |
2.14 |
-0.5 |
| PK |
250.0 |
2.14 |
-0.5 |
| PK |
400.0 |
2.14 |
-0.25 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.25 |
| PK |
1600.0 |
2.14 |
0.0 |
| PK |
2500.0 |
2.14 |
0.25 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
0.25 |
| PK |
10000.0 |
2.14 |
0.25 |
| PK |
16000.0 |
2.14 |
0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.5dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
-0.25 |
| PK |
50.0 |
4.32 |
-0.5 |
| PK |
63.0 |
4.32 |
-0.5 |
| PK |
80.0 |
4.32 |
-0.5 |
| PK |
100.0 |
4.32 |
-0.5 |
| PK |
125.0 |
4.32 |
-0.5 |
| PK |
160.0 |
4.32 |
-0.5 |
| PK |
200.0 |
4.32 |
-0.5 |
| PK |
250.0 |
4.32 |
-0.5 |
| PK |
315.0 |
4.32 |
-0.5 |
| PK |
400.0 |
4.32 |
-0.25 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.25 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.25 |
| PK |
3150.0 |
4.32 |
0.25 |
| PK |
4000.0 |
4.32 |
0.0 |
| PK |
5000.0 |
4.32 |
0.0 |
| PK |
6300.0 |
4.32 |
0.25 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.25 |
| PK |
12000.0 |
4.32 |
0.0 |
| PK |
16000.0 |
4.32 |
0.5 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
