What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Sound and Recording.
-
Format of the data is
a scanned image
.
-
-3dB (resp. -6db) point v.s. reference is at 28.7Hz (resp. 27.3Hz).
-
Reference level is normalised to 0.8dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.5dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.68
and would be 5.84 with a
perfect subwoofer.
- Details:
NBD: ON 0.564,
LW 0.517, SP
0.554, PIR
0.502; SM:
SP0.663,
PIR0.461; LFQ
1.814, LFX 26Hz
- Tonality (Preference) Score is 6.82
with an EQ and would be 7.94 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.384,
LW 0.32, SP
0.364, PIR
0.294; SM:
SP0.911,
PIR0.905; LFQ 1.814, LFX 26Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -1.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
85.0 |
0.8 |
-3.97 |
| PK |
356.0 |
1.95 |
-2.27 |
| PK |
560.0 |
2.1 |
3.0 |
| PK |
792.0 |
3.0 |
-1.96 |
| PK |
2324.0 |
2.99 |
2.11 |
| PK |
4654.0 |
0.47 |
-3.71 |
| PK |
13652.0 |
2.91 |
-3.65 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
-0.25 |
| PK |
63.0 |
2.14 |
-0.5 |
| PK |
100.0 |
2.14 |
-0.75 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
-0.25 |
| PK |
400.0 |
2.14 |
-0.25 |
| PK |
630.0 |
2.14 |
0.25 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.0 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
-0.25 |
| PK |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.0 |
| PK |
40.0 |
4.32 |
-0.25 |
| PK |
50.0 |
4.32 |
-0.25 |
| PK |
63.0 |
4.32 |
-0.5 |
| PK |
80.0 |
4.32 |
-0.5 |
| PK |
100.0 |
4.32 |
-0.5 |
| PK |
125.0 |
4.32 |
-0.5 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
-0.25 |
| PK |
250.0 |
4.32 |
-0.25 |
| PK |
315.0 |
4.32 |
-0.25 |
| PK |
400.0 |
4.32 |
-0.25 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
0.25 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
-0.25 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.5 |
| PK |
6300.0 |
4.32 |
-0.5 |
| PK |
8000.0 |
4.32 |
-0.5 |
| PK |
10000.0 |
4.32 |
-0.25 |
| PK |
12000.0 |
4.32 |
-0.25 |
| PK |
16000.0 |
4.32 |
-0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
