What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 60.1Hz (resp. 54.2Hz).
-
Reference level is normalised to -0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 5.2dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-40.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 2.82
and would be 5.29 with a
perfect subwoofer.
- Details:
NBD: ON 0.82,
LW 0.702, SP
0.816, PIR
0.703; SM:
SP0.85,
PIR0.755; LFQ
0.664, LFX 54Hz
- Tonality (Preference) Score is 4.42
with an EQ and would be 6.89 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.67,
LW 0.489, SP
0.5, PIR
0.399; SM:
SP0.921,
PIR0.891; LFQ 0.664, LFX 54Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
106.0 |
1.29 |
-2.98 |
| 3 |
148.0 |
2.72 |
-0.57 |
| 3 |
378.0 |
2.77 |
0.52 |
| 3 |
817.0 |
2.97 |
2.78 |
| 3 |
965.0 |
2.38 |
-2.99 |
| 3 |
1648.0 |
2.96 |
-2.67 |
| 3 |
2302.0 |
1.8 |
2.97 |
| 3 |
6069.0 |
2.92 |
2.87 |
| 3 |
7669.0 |
0.91 |
-2.51 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -5.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
489.0 |
15.0 |
-1.1 |
| 3 |
691.0 |
11.0 |
-1.1 |
| 3 |
795.0 |
9.5 |
3.4 |
| 3 |
878.0 |
12.0 |
-2.3 |
| 3 |
990.0 |
9.0 |
-2.5 |
| 3 |
1111.0 |
7.0 |
-1.5 |
| 3 |
1254.0 |
15.0 |
1.8 |
| 3 |
1385.0 |
15.0 |
-1.7 |
| 3 |
1689.0 |
6.0 |
-2.8 |
| 3 |
1926.0 |
15.0 |
2.1 |
| 3 |
2315.0 |
8.5 |
3.6 |
| 3 |
2688.0 |
7.5 |
4.7 |
| 3 |
3070.0 |
10.0 |
-1.1 |
| 3 |
3630.0 |
8.0 |
1.2 |
| 3 |
4270.0 |
10.0 |
-1.4 |
| 3 |
4970.0 |
16.0 |
-1.3 |
| 3 |
5840.0 |
8.0 |
1.4 |
| 3 |
7910.0 |
6.0 |
-2.3 |
| 3 |
9820.0 |
10.0 |
-1.8 |
| 3 |
13100.0 |
7.0 |
-1.3 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.25 |
| 3 |
40.0 |
2.14 |
0.25 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
-0.5 |
| 3 |
160.0 |
2.14 |
-0.25 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
-0.25 |
| 3 |
1600.0 |
2.14 |
-0.25 |
| 3 |
2500.0 |
2.14 |
0.75 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
0.5 |
| 3 |
10000.0 |
2.14 |
0.0 |
| 3 |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.5dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.25 |
| 3 |
31.0 |
4.32 |
0.25 |
| 3 |
40.0 |
4.32 |
0.25 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
-0.25 |
| 3 |
100.0 |
4.32 |
-0.5 |
| 3 |
125.0 |
4.32 |
-0.5 |
| 3 |
160.0 |
4.32 |
-0.25 |
| 3 |
200.0 |
4.32 |
-0.25 |
| 3 |
250.0 |
4.32 |
-0.25 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
-0.25 |
| 3 |
630.0 |
4.32 |
-0.25 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
-0.25 |
| 3 |
2000.0 |
4.32 |
0.25 |
| 3 |
2500.0 |
4.32 |
0.5 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
0.0 |
| 3 |
6300.0 |
4.32 |
0.25 |
| 3 |
8000.0 |
4.32 |
-0.25 |
| 3 |
10000.0 |
4.32 |
0.0 |
| 3 |
12000.0 |
4.32 |
0.0 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
