What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is FBT.
-
Format of the data is
a GLL file
.
-
-3dB (resp. -6db) point v.s. reference is at 53.0Hz (resp. 48.7Hz).
-
Reference level is normalised to -0.9dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 11.4dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-10.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 2.64
and would be 4.86 with a
perfect subwoofer.
- Details:
NBD: ON 0.825,
LW 0.733, SP
0.796, PIR
0.758; SM:
SP0.77,
PIR0.648; LFQ
0.405, LFX 47Hz
- Tonality (Preference) Score is 5.42
with an EQ and would be 7.74 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.409,
LW 0.323, SP
0.384, PIR
0.333; SM:
SP0.927,
PIR0.895; LFQ 0.432, LFX 49Hz
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -6.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
93.0 |
1.28 |
-2.97 |
| PK |
117.0 |
1.4 |
-2.15 |
| PK |
221.0 |
1.43 |
2.93 |
| PK |
262.0 |
2.0 |
2.94 |
| PK |
309.0 |
2.4 |
2.96 |
| PK |
625.0 |
0.76 |
-2.1 |
| PK |
3438.0 |
2.47 |
2.91 |
| PK |
5310.0 |
1.83 |
2.99 |
| PK |
6276.0 |
1.16 |
2.93 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.5dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
-0.25 |
| PK |
100.0 |
2.14 |
-0.75 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
0.75 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
0.0 |
| PK |
2500.0 |
2.14 |
0.25 |
| PK |
4000.0 |
2.14 |
1.0 |
| PK |
6300.0 |
2.14 |
1.25 |
| PK |
10000.0 |
2.14 |
0.75 |
| PK |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
-0.25 |
| PK |
80.0 |
4.32 |
-0.5 |
| PK |
100.0 |
4.32 |
-0.5 |
| PK |
125.0 |
4.32 |
-0.5 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.25 |
| PK |
250.0 |
4.32 |
0.5 |
| PK |
315.0 |
4.32 |
0.5 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
-0.25 |
| PK |
630.0 |
4.32 |
-0.25 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.25 |
| PK |
3150.0 |
4.32 |
0.75 |
| PK |
4000.0 |
4.32 |
0.75 |
| PK |
5000.0 |
4.32 |
1.25 |
| PK |
6300.0 |
4.32 |
1.0 |
| PK |
8000.0 |
4.32 |
0.5 |
| PK |
10000.0 |
4.32 |
0.75 |
| PK |
12000.0 |
4.32 |
0.5 |
| PK |
16000.0 |
4.32 |
-0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
