What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 58.6Hz (resp. 51.3Hz).
-
Reference level is normalised to -0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.9dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-30.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-60.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.83
and would be 6.2 with a
perfect subwoofer.
- Details:
NBD: ON 0.67,
LW 0.596, SP
0.581, PIR
0.496; SM:
SP0.798,
PIR0.72; LFQ
0.642, LFX 51Hz
- Tonality (Preference) Score is 5.3
with an EQ and would be 7.44 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.515,
LW 0.432, SP
0.493, PIR
0.351; SM:
SP0.906,
PIR0.901; LFQ 0.627, LFX 45Hz
- Link to Original review.
AutomaticEQ (IIR)
|
Set preamp gain to: -2.7dB.
|
Type |
Freq |
Q |
Gain |
3 |
47.0 |
1.95 |
2.99 |
3 |
80.0 |
1.52 |
-1.68 |
3 |
369.0 |
0.36 |
1.27 |
3 |
820.0 |
2.98 |
-1.51 |
3 |
2406.0 |
2.96 |
-2.99 |
3 |
5934.0 |
2.98 |
-3.7 |
3 |
11085.0 |
2.99 |
-1.21 |
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
Graphic EQ 15 bands
|
Set preamp gain to: -0.3dB.
|
Type |
Freq |
Q |
Gain |
3 |
25.0 |
2.14 |
0.25 |
3 |
40.0 |
2.14 |
0.25 |
3 |
63.0 |
2.14 |
0.0 |
3 |
100.0 |
2.14 |
-0.25 |
3 |
160.0 |
2.14 |
0.0 |
3 |
250.0 |
2.14 |
0.25 |
3 |
400.0 |
2.14 |
0.0 |
3 |
630.0 |
2.14 |
0.0 |
3 |
1000.0 |
2.14 |
0.0 |
3 |
1600.0 |
2.14 |
0.0 |
3 |
2500.0 |
2.14 |
-0.25 |
3 |
4000.0 |
2.14 |
-0.25 |
3 |
6300.0 |
2.14 |
-0.25 |
3 |
10000.0 |
2.14 |
0.25 |
3 |
16000.0 |
2.14 |
0.25 |
Download
|
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
|
Set preamp gain to: -0.4dB.
|
Type |
Freq |
Q |
Gain |
3 |
20.0 |
4.32 |
0.0 |
3 |
25.0 |
4.32 |
0.25 |
3 |
31.0 |
4.32 |
0.25 |
3 |
40.0 |
4.32 |
0.25 |
3 |
50.0 |
4.32 |
0.25 |
3 |
63.0 |
4.32 |
0.0 |
3 |
80.0 |
4.32 |
-0.25 |
3 |
100.0 |
4.32 |
-0.25 |
3 |
125.0 |
4.32 |
0.0 |
3 |
160.0 |
4.32 |
0.0 |
3 |
200.0 |
4.32 |
0.0 |
3 |
250.0 |
4.32 |
0.25 |
3 |
315.0 |
4.32 |
0.25 |
3 |
400.0 |
4.32 |
0.0 |
3 |
500.0 |
4.32 |
0.25 |
3 |
630.0 |
4.32 |
0.0 |
3 |
800.0 |
4.32 |
-0.25 |
3 |
1000.0 |
4.32 |
0.0 |
3 |
1250.0 |
4.32 |
0.0 |
3 |
1600.0 |
4.32 |
0.0 |
3 |
2000.0 |
4.32 |
0.0 |
3 |
2500.0 |
4.32 |
-0.5 |
3 |
3150.0 |
4.32 |
-0.25 |
3 |
4000.0 |
4.32 |
-0.25 |
3 |
5000.0 |
4.32 |
0.25 |
3 |
6300.0 |
4.32 |
-0.25 |
3 |
8000.0 |
4.32 |
0.25 |
3 |
10000.0 |
4.32 |
0.25 |
3 |
12000.0 |
4.32 |
0.25 |
3 |
16000.0 |
4.32 |
0.25 |
3 |
20000.0 |
4.32 |
0.0 |
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
