What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Princeton.
-
Format of the data is
.
-
Sensitivity: 84.0dB (avg. 100Hz-1kHz for 2.83V estimated at 1m)
-
Reference level is normalised to -1.4dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 5.2dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for panel speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is -0.89
and would be 5.77 with a
perfect subwoofer.
- Details:
NBD: ON 0.653,
LW 0.692, SP
0.731, PIR
0.638; SM:
SP0.778,
PIR0.7; LFQ
10.0, LFX 509Hz
- Tonality (Preference) Score is -0.94
with an EQ and would be 5.71 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.652,
LW 0.649, SP
0.718, PIR
0.618; SM:
SP0.772,
PIR0.65; LFQ 10.0, LFX 509Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.9dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
22.0 |
0.52 |
-7.48 |
| 3 |
47.0 |
0.27 |
-8.7 |
| 3 |
105.0 |
0.34 |
-7.63 |
| 3 |
1121.0 |
1.03 |
-4.22 |
| 3 |
3177.0 |
0.55 |
2.17 |
| 3 |
6361.0 |
2.12 |
1.76 |
| 3 |
14134.0 |
1.56 |
0.16 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.0 |
| 3 |
40.0 |
2.14 |
0.0 |
| 3 |
63.0 |
2.14 |
0.0 |
| 3 |
100.0 |
2.14 |
0.0 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
-0.25 |
| 3 |
1000.0 |
2.14 |
0.0 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
0.5 |
| 3 |
4000.0 |
2.14 |
0.75 |
| 3 |
6300.0 |
2.14 |
0.75 |
| 3 |
10000.0 |
2.14 |
1.0 |
| 3 |
16000.0 |
2.14 |
0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.0 |
| 3 |
31.0 |
4.32 |
0.0 |
| 3 |
40.0 |
4.32 |
0.0 |
| 3 |
50.0 |
4.32 |
0.0 |
| 3 |
63.0 |
4.32 |
0.0 |
| 3 |
80.0 |
4.32 |
0.0 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
-0.25 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
0.0 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
0.25 |
| 3 |
2000.0 |
4.32 |
0.5 |
| 3 |
2500.0 |
4.32 |
0.5 |
| 3 |
3150.0 |
4.32 |
0.75 |
| 3 |
4000.0 |
4.32 |
0.75 |
| 3 |
5000.0 |
4.32 |
0.75 |
| 3 |
6300.0 |
4.32 |
0.75 |
| 3 |
8000.0 |
4.32 |
1.0 |
| 3 |
10000.0 |
4.32 |
1.0 |
| 3 |
12000.0 |
4.32 |
1.0 |
| 3 |
16000.0 |
4.32 |
0.5 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
