What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 49.1Hz (resp. 41.4Hz).
-
Reference level is normalised to 0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.0dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.8
and would be 6.69 with a
perfect subwoofer.
- Details:
NBD: ON 0.465,
LW 0.464, SP
0.461, PIR
0.43; SM:
SP0.81,
PIR0.63; LFQ
0.332, LFX 39Hz
- Tonality (Preference) Score is 6.42
with an EQ and would be 8.12 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.326,
LW 0.31, SP
0.365, PIR
0.304; SM:
SP0.943,
PIR0.932; LFQ 0.332, LFX 35Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -4.3dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
64.0 |
0.48 |
2.75 |
| PK |
102.0 |
0.68 |
-2.85 |
| PK |
289.0 |
1.34 |
0.86 |
| PK |
529.0 |
2.31 |
1.6 |
| PK |
668.0 |
2.99 |
-2.91 |
| PK |
1103.0 |
2.65 |
-2.18 |
| PK |
4645.0 |
2.83 |
-1.88 |
| PK |
5490.0 |
0.71 |
-2.75 |
| LS |
16000.0 |
0.89 |
1.78 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -0.9dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
467.0 |
12.0 |
1.2 |
| PK |
563.0 |
10.0 |
1.4 |
| PK |
635.0 |
10.0 |
-2.9 |
| PK |
722.0 |
4.0 |
-1.8 |
| PK |
1041.0 |
4.2 |
-2.2 |
| PK |
1627.0 |
1.0 |
-1.0 |
| PK |
1930.0 |
17.0 |
0.7 |
| PK |
2090.0 |
25.0 |
-0.9 |
| PK |
2536.0 |
5.0 |
1.3 |
| PK |
2619.0 |
1.0 |
-1.2 |
| PK |
3460.0 |
15.0 |
0.8 |
| PK |
4694.0 |
5.0 |
-1.3 |
| PK |
5300.0 |
10.0 |
-0.4 |
| PK |
6101.0 |
5.0 |
2.4 |
| PK |
7355.0 |
1.149 |
-5.6 |
| PK |
7901.0 |
5.0 |
5.1 |
| PK |
9028.0 |
5.0 |
-2.6 |
| PK |
9547.0 |
5.0 |
3.5 |
| PK |
12101.0 |
5.0 |
2.6 |
| PK |
12944.0 |
5.0 |
-1.5 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.25 |
| PK |
100.0 |
2.14 |
-0.25 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.25 |
| PK |
400.0 |
2.14 |
0.25 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
-0.25 |
| PK |
2500.0 |
2.14 |
-0.25 |
| PK |
4000.0 |
2.14 |
-0.5 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
-0.25 |
| PK |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.25 |
| PK |
80.0 |
4.32 |
0.0 |
| PK |
100.0 |
4.32 |
-0.25 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.25 |
| PK |
315.0 |
4.32 |
0.25 |
| PK |
400.0 |
4.32 |
0.25 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
-0.5 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
-0.25 |
| PK |
1600.0 |
4.32 |
-0.25 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
-0.25 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.5 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
0.0 |
| PK |
10000.0 |
4.32 |
0.0 |
| PK |
12000.0 |
4.32 |
0.25 |
| PK |
16000.0 |
4.32 |
0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
