What we know about the measurement:
Quality of the measurement data is
high .
Origin of the data is ASR.
Format of the data is
generated by a Klippel NFS
.
Sensitivity: 83.2 dB (avg. 100Hz-1kHz for 2.83V measured at 1m ).
-3dB (resp. -6db) point v.s. reference is at 55.7Hz (resp. 48.3Hz).
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
Frequency deviation is 5.4dB over the same frequency range.
Directivity
Horizontal directivity
is (-70.0°, 60.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Vertical directivity
is (-30.0°, 10.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Tonality (Preference) Score
Tonality (Preference) Score is 5.13
and would be 7.26 with a
perfect subwoofer.
Details:
NBD: ON 0.454,
LW 0.444, SP
0.388, PIR
0.381; SM:
SP0.888,
PIR0.799; LFQ
0.451, LFX 45Hz
Tonality (Preference) Score is 6.29
with an EQ and would be 8.24 with a
perfect subwoofer and the same EQ.
Details:
NBD: ON 0.336,
LW 0.312, SP
0.326, PIR
0.26; SM:
SP0.953,
PIR0.938; LFQ 0.451, LFX 41Hz
Link to Original review .
AutomaticEQ (IIR)
Set preamp gain to: -2.9dB .
Type
Freq
Q
Gain
5
55.0
0.52
2.7
3
55.0
1.68
1.92
3
121.0
0.9
-1.92
3
404.0
2.54
1.69
3
478.0
2.63
-0.94
3
1220.0
2.79
1.15
3
2721.0
2.98
2.53
3
2813.0
3.0
2.82
3
3216.0
1.22
-2.94
Download
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
maiky76@ASR LW (IIR)
Set preamp gain to: -3.0dB .
Type
Freq
Q
Gain
1
55.92
1.4
0.0
3
100.95
0.89
-2.88
3
370.8
2.7
1.17
3
1422.38
1.63
0.84
3
2043.64
4.46
-1.71
3
2823.57
1.92
3.54
3
3592.12
4.47
-3.33
3
10695.84
1.71
2.46
Download
These EQ is designed by ASR member maiky76. These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
maiky76@ASR (IIR)
Set preamp gain to: -3.0dB .
Type
Freq
Q
Gain
1
55.92
1.4
0.0
3
102.45
0.89
-2.9
3
377.8
3.43
1.17
3
1181.11
4.64
0.87
3
2110.76
3.28
-1.43
3
2781.53
2.53
4.2
3
3570.41
4.47
-3.33
3
5496.79
0.57
-0.62
3
10694.84
2.5
1.66
Download
These EQ is designed by ASR member maiky76. These EQ optimise the Harman score and is a good start for far field listening like in your living room.
Graphic EQ 15 bands
Set preamp gain to: -0.6dB .
Type
Freq
Q
Gain
3
25.0
2.14
0.5
3
40.0
2.14
0.5
3
63.0
2.14
0.25
3
100.0
2.14
-0.25
3
160.0
2.14
-0.25
3
250.0
2.14
0.0
3
400.0
2.14
0.25
3
630.0
2.14
0.0
3
1000.0
2.14
0.0
3
1600.0
2.14
0.25
3
2500.0
2.14
0.25
3
4000.0
2.14
-0.25
3
6300.0
2.14
0.0
3
10000.0
2.14
0.25
3
16000.0
2.14
0.0
Download
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
Set preamp gain to: -0.7dB .
Type
Freq
Q
Gain
3
20.0
4.32
0.0
3
25.0
4.32
0.5
3
31.0
4.32
0.5
3
40.0
4.32
0.5
3
50.0
4.32
0.5
3
63.0
4.32
0.25
3
80.0
4.32
0.0
3
100.0
4.32
-0.25
3
125.0
4.32
-0.25
3
160.0
4.32
-0.25
3
200.0
4.32
-0.25
3
250.0
4.32
0.0
3
315.0
4.32
0.0
3
400.0
4.32
0.0
3
500.0
4.32
0.0
3
630.0
4.32
0.0
3
800.0
4.32
-0.25
3
1000.0
4.32
0.0
3
1250.0
4.32
0.0
3
1600.0
4.32
0.25
3
2000.0
4.32
0.0
3
2500.0
4.32
0.25
3
3150.0
4.32
0.0
3
4000.0
4.32
-0.25
3
5000.0
4.32
0.0
3
6300.0
4.32
0.0
3
8000.0
4.32
-0.25
3
10000.0
4.32
0.25
3
12000.0
4.32
0.25
3
16000.0
4.32
0.0
3
20000.0
4.32
0.0
Download
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
