What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 63.0Hz (resp. 58.6Hz).
-
Reference level is normalised to 0.5dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 5.5dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 1.84
and would be 4.45 with a
perfect subwoofer.
- Details:
NBD: ON 0.8,
LW 0.65, SP
0.541, PIR
0.557; SM:
SP0.591,
PIR0.184; LFQ
0.543, LFX 58Hz
- Tonality (Preference) Score is 5.57
with an EQ and would be 7.99 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.391,
LW 0.33, SP
0.333, PIR
0.284; SM:
SP0.957,
PIR0.921; LFQ 0.543, LFX 52Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
49.0 |
2.8 |
2.82 |
| 3 |
95.0 |
2.88 |
-2.91 |
| 3 |
409.0 |
1.58 |
2.17 |
| 3 |
1288.0 |
1.8 |
-3.44 |
| 3 |
2168.0 |
2.98 |
2.55 |
| 3 |
4654.0 |
2.98 |
-5.39 |
| 3 |
8694.0 |
1.39 |
-5.08 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
maiky76@ASR (IIR)
|
|
Set preamp gain to: -3.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
95.0 |
2.72 |
-3.5 |
| 3 |
168.0 |
1.45 |
-1.0 |
| 3 |
1167.0 |
4.25 |
-3.5 |
| 3 |
1550.0 |
2.57 |
-3.4 |
| 3 |
2086.0 |
3.37 |
1.71 |
| 3 |
3371.0 |
2.62 |
-1.71 |
| 3 |
4718.0 |
3.88 |
-5.8 |
| 3 |
7704.0 |
2.98 |
-4.12 |
| 3 |
10002.0 |
2.0 |
-3.16 |
| 3 |
12017.0 |
3.0 |
-0.71 |
| 3 |
16397.0 |
3.49 |
3.5 |
|
Download
|
These EQ is designed by ASR member maiky76. These EQ optimise the Harman score and is a good start for far field listening like in your living room.
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -2.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
423.0 |
6.0 |
2.3 |
| 3 |
460.0 |
13.0 |
-1.6 |
| 3 |
1110.0 |
20.0 |
-0.7 |
| 3 |
1170.0 |
4.185 |
-4.3 |
| 3 |
1180.0 |
15.0 |
0.6 |
| 3 |
1321.0 |
15.0 |
-0.4 |
| 3 |
1495.0 |
5.0 |
-3.0 |
| 3 |
1846.0 |
5.0 |
-4.3 |
| 3 |
2002.0 |
4.994 |
12.0 |
| 3 |
2053.0 |
5.0 |
-8.0 |
| 3 |
2267.0 |
5.0 |
1.4 |
| 3 |
2390.0 |
20.0 |
-0.9 |
| 3 |
4106.0 |
3.329 |
2.3 |
| 3 |
4599.0 |
1.677 |
-6.8 |
| 3 |
5651.0 |
5.0 |
3.1 |
| 3 |
6361.0 |
5.0 |
1.4 |
| 3 |
7580.0 |
12.0 |
-0.5 |
| 3 |
8427.0 |
1.0 |
-5.4 |
| 3 |
12300.0 |
3.5 |
-1.4 |
| 3 |
15850.0 |
1.3 |
2.3 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.25 |
| 3 |
40.0 |
2.14 |
0.25 |
| 3 |
63.0 |
2.14 |
0.0 |
| 3 |
100.0 |
2.14 |
-0.25 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.25 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
-0.25 |
| 3 |
1600.0 |
2.14 |
-0.5 |
| 3 |
2500.0 |
2.14 |
0.0 |
| 3 |
4000.0 |
2.14 |
-0.75 |
| 3 |
6300.0 |
2.14 |
-0.5 |
| 3 |
10000.0 |
2.14 |
-0.75 |
| 3 |
16000.0 |
2.14 |
0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.0 |
| 3 |
31.0 |
4.32 |
0.0 |
| 3 |
40.0 |
4.32 |
0.0 |
| 3 |
50.0 |
4.32 |
0.0 |
| 3 |
63.0 |
4.32 |
0.0 |
| 3 |
80.0 |
4.32 |
-0.25 |
| 3 |
100.0 |
4.32 |
-0.25 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.25 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
-0.5 |
| 3 |
1600.0 |
4.32 |
-0.5 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
0.0 |
| 3 |
3150.0 |
4.32 |
-0.25 |
| 3 |
4000.0 |
4.32 |
-0.5 |
| 3 |
5000.0 |
4.32 |
-0.75 |
| 3 |
6300.0 |
4.32 |
-0.5 |
| 3 |
8000.0 |
4.32 |
-0.75 |
| 3 |
10000.0 |
4.32 |
-0.5 |
| 3 |
12000.0 |
4.32 |
-0.5 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
