What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 71.8Hz (resp. 63.0Hz).
-
Reference level is normalised to 0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.9dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.62
and would be 8.28 with a
perfect subwoofer.
- Details:
NBD: ON 0.272,
LW 0.242, SP
0.315, PIR
0.262; SM:
SP0.961,
PIR0.888; LFQ
0.44, LFX 60Hz
- Tonality (Preference) Score is 6.46
with an EQ and would be 8.92 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.2,
LW 0.174, SP
0.232, PIR
0.171; SM:
SP0.986,
PIR0.972; LFQ 0.44, LFX 54Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
58.0 |
1.38 |
2.9 |
| 3 |
113.0 |
1.02 |
-2.61 |
| 3 |
382.0 |
0.69 |
2.26 |
| 3 |
560.0 |
1.15 |
-2.13 |
| 3 |
2245.0 |
2.99 |
-0.93 |
| 3 |
6585.0 |
0.87 |
-0.83 |
| 3 |
16239.0 |
2.76 |
-1.38 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
338.0 |
4.0 |
0.4 |
| 3 |
435.0 |
10.0 |
0.8 |
| 3 |
497.0 |
7.0 |
-0.6 |
| 3 |
616.0 |
8.0 |
-0.4 |
| 3 |
700.0 |
6.0 |
0.5 |
| 3 |
795.0 |
1.0 |
-1.4 |
| 3 |
1004.0 |
14.0 |
-0.7 |
| 3 |
1167.0 |
11.0 |
0.4 |
| 3 |
1510.0 |
15.0 |
-0.7 |
| 3 |
1742.0 |
5.0 |
9.4 |
| 3 |
1742.0 |
5.0 |
9.4 |
| 3 |
1747.0 |
5.0 |
-18.6 |
| 3 |
2555.0 |
25.0 |
0.7 |
| 3 |
3956.0 |
2.076 |
-1.7 |
| 3 |
5140.0 |
9.0 |
0.3 |
| 3 |
7171.0 |
3.5 |
-0.2 |
| 3 |
10159.0 |
1.0 |
-1.5 |
| 3 |
10880.0 |
3.0 |
0.3 |
| 3 |
13180.0 |
4.0 |
-0.4 |
| 3 |
15385.0 |
5.0 |
-2.0 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.5 |
| 3 |
40.0 |
2.14 |
0.5 |
| 3 |
63.0 |
2.14 |
0.5 |
| 3 |
100.0 |
2.14 |
-0.5 |
| 3 |
160.0 |
2.14 |
-0.5 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
-0.25 |
| 3 |
1000.0 |
2.14 |
0.0 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
-0.25 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
-0.25 |
| 3 |
10000.0 |
2.14 |
-0.25 |
| 3 |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.25 |
| 3 |
31.0 |
4.32 |
0.25 |
| 3 |
40.0 |
4.32 |
0.25 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
0.0 |
| 3 |
100.0 |
4.32 |
-0.25 |
| 3 |
125.0 |
4.32 |
-0.5 |
| 3 |
160.0 |
4.32 |
-0.25 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
-0.25 |
| 3 |
800.0 |
4.32 |
-0.25 |
| 3 |
1000.0 |
4.32 |
0.0 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
0.25 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
-0.25 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
0.0 |
| 3 |
6300.0 |
4.32 |
-0.25 |
| 3 |
8000.0 |
4.32 |
-0.25 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
0.0 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
