What we know about the measurement:

DIYSG Elusive 1099 is a passive bookshelves that cost around 820 USD for a pair.

  • Quality of the measurement data is high.
  • Origin of the data is ErinsAudioCorner.
  • Format of the data is generated by a Klippel NFS .
  • Sensitivity: 95.7dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
  • -3dB (resp. -6db) point v.s. reference is at 98.1Hz (resp. 74.7Hz).
  • Reference level is normalised to 0.1dB computed over the frequency range [300.0Hz, 5000.0Hz].
  • Frequency deviation is 3.4dB over the same frequency range.
  • Directivity
    • Horizontal directivity is (-40.0°, 40.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
    • Vertical directivity is (-20.0°, 20.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
  • Tonality (Preference) Score
    • Tonality (Preference) Score is 2.27 and would be 5.45 with a perfect subwoofer.
      • Details: NBD: ON 0.585, LW 0.545, SP 0.542, PIR 0.52; SM: SP0.741, PIR0.338; LFQ 2.979, LFX 79Hz
    • Tonality (Preference) Score is 5.53 with an EQ and would be 7.89 with a perfect subwoofer and the same EQ.
      • Details: NBD: ON 0.352, LW 0.315, SP 0.426, PIR 0.338; SM: SP0.936, PIR0.905; LFQ 2.503, LFX 51Hz
  • Link to original Review: eac review. Links to other reviews: asr review , avs review .
DIYSG Elusive 1099
AutomaticEQ (IIR)
Set preamp gain to: -4.5dB.
Type Freq Q Gain
3 42.0 0.54 2.96
3 149.0 1.52 -4.52
3 155.0 0.26 2.97
3 560.0 1.91 -4.17
3 3177.0 1.26 1.89
3 4654.0 2.84 -3.36
3 8694.0 0.8 -3.61
Download

These EQ optimise the Harman score and is a good start for far field listening like in your living room.

DIYSG Elusive 1099 filters_auto_eq

AutomaticEQ

DIYSG Elusive 1099 filters_eq_full

Target v.s. EQ

DIYSG Elusive 1099
Graphic EQ 15 bands
Set preamp gain to: -1.1dB.
Type Freq Q Gain
3 25.0 2.14 0.75
3 40.0 2.14 0.75
3 63.0 2.14 0.75
3 100.0 2.14 0.75
3 160.0 2.14 0.25
3 250.0 2.14 0.75
3 400.0 2.14 0.25
3 630.0 2.14 0.0
3 1000.0 2.14 0.25
3 1600.0 2.14 0.5
3 2500.0 2.14 0.25
3 4000.0 2.14 -0.25
3 6300.0 2.14 -0.5
3 10000.0 2.14 -0.5
3 16000.0 2.14 0.0
Download

These EQ is designed for a 15 bands graphical EQ.

DIYSG Elusive 1099
Graphic EQ 31 bands
Set preamp gain to: -0.8dB.
Type Freq Q Gain
3 20.0 4.32 0.0
3 25.0 4.32 0.5
3 31.0 4.32 0.5
3 40.0 4.32 0.5
3 50.0 4.32 0.5
3 63.0 4.32 0.5
3 80.0 4.32 0.5
3 100.0 4.32 0.5
3 125.0 4.32 0.0
3 160.0 4.32 0.0
3 200.0 4.32 0.0
3 250.0 4.32 0.25
3 315.0 4.32 0.25
3 400.0 4.32 -0.25
3 500.0 4.32 -0.5
3 630.0 4.32 -0.5
3 800.0 4.32 0.0
3 1000.0 4.32 0.0
3 1250.0 4.32 -0.25
3 1600.0 4.32 0.0
3 2000.0 4.32 0.25
3 2500.0 4.32 0.0
3 3150.0 4.32 0.0
3 4000.0 4.32 -0.5
3 5000.0 4.32 -0.75
3 6300.0 4.32 -0.5
3 8000.0 4.32 -0.75
3 10000.0 4.32 -0.5
3 12000.0 4.32 -0.5
3 16000.0 4.32 -0.25
3 20000.0 4.32 0.0
Download

These EQ is designed for a 31 bands graphical EQ.

DIYSG Elusive 1099: comparison between EQs
DIYSG Elusive 1099

Comparison betweens various EQs

DIYSG Elusive 1099

Improvements made by EQ
CEA2034
On Axis
Early Reflections
Estimated In-Room Response
Horizontal Reflections
Vertical Reflections
SPL Horizontal
SPL Vertical
SPL Horizontal Normalized
SPL Vertical Normalized
SPL Horizontal Contour
SPL Vertical Contour
SPL Horizontal Contour Normalized
SPL Vertical Contour Normalized
SPL Horizontal Contour 3D
SPL Vertical Contour 3D
SPL Horizontal Contour Normalized 3D
SPL Vertical Contour Normalized 3D
SPL Horizontal Radar
SPL Vertical Radar
CEA2034
On Axis
Early Reflections
Estimated In-Room Response
Horizontal Reflections
Vertical Reflections
SPL Horizontal
SPL Vertical
SPL Horizontal Normalized
SPL Vertical Normalized
SPL Horizontal Contour
SPL Vertical Contour
SPL Horizontal Contour Normalized
SPL Vertical Contour Normalized
SPL Horizontal Contour 3D
SPL Vertical Contour 3D
SPL Horizontal Contour Normalized 3D
SPL Vertical Contour Normalized 3D
SPL Horizontal Radar
SPL Vertical Radar
Frequency Frequency with EQ
Frequency Frequency with EQ
Frequency Frequency with EQ
Frequency Frequency with EQ
Frequency Frequency with EQ
Frequency Frequency with EQ
Frequency Frequency with EQ
Frequency Frequency with EQ
Frequency Frequency with EQ
Frequency Frequency with EQ
;
