What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 64.5Hz (resp. 58.6Hz).
-
Reference level is normalised to -0.5dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 7.4dB over the same frequency range.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for omnidirectional speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is -0.22
and would be 2.39 with a
perfect subwoofer.
- Details:
NBD: ON 1.418,
LW 1.3, SP
0.884, PIR
1.023; SM:
SP0.679,
PIR0.56; LFQ
0.381, LFX 58Hz
- Tonality (Preference) Score is 2.48
with an EQ and would be 5.0 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.977,
LW 0.822, SP
0.606, PIR
0.629; SM:
SP0.739,
PIR0.703; LFQ 0.381, LFX 55Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
84.0 |
2.97 |
-3.0 |
| PK |
209.0 |
2.82 |
-1.86 |
| PK |
6471.0 |
2.84 |
-5.98 |
| PK |
15857.0 |
1.11 |
2.87 |
| PK |
3209.0 |
2.99 |
2.99 |
| PK |
1547.0 |
2.12 |
-5.45 |
| PK |
875.0 |
2.98 |
-2.87 |
| PK |
476.0 |
1.22 |
0.82 |
| PK |
6563.0 |
2.99 |
-5.27 |
|
Download
|
This EQ optimise the Harman score and is a good start for far field listening like in your living room.
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -8.2dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
400.0 |
4.0 |
1.2 |
| PK |
532.0 |
8.0 |
1.8 |
| PK |
935.0 |
5.0 |
-2.0 |
| PK |
1075.0 |
5.0 |
3.6 |
| PK |
1352.0 |
5.0 |
2.0 |
| PK |
1561.0 |
5.0 |
-3.7 |
| PK |
2005.0 |
5.0 |
8.6 |
| PK |
2122.0 |
5.0 |
-9.6 |
| PK |
2232.0 |
5.0 |
6.6 |
| PK |
2756.0 |
2.184 |
9.3 |
| PK |
3066.0 |
1.0 |
-9.7 |
| PK |
3298.0 |
5.0 |
9.2 |
| PK |
4752.0 |
5.0 |
16.3 |
| PK |
5150.0 |
5.0 |
-9.1 |
| PK |
6171.0 |
1.103 |
-1.4 |
| PK |
7041.0 |
5.0 |
-8.9 |
| PK |
8747.0 |
2.115 |
12.6 |
| PK |
9066.0 |
5.0 |
-6.3 |
| PK |
10744.0 |
5.0 |
-4.9 |
| PK |
13500.0 |
8.0 |
7.5 |
|
Download
|
This EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.25 |
| PK |
100.0 |
2.14 |
-0.5 |
| PK |
160.0 |
2.14 |
-0.5 |
| PK |
250.0 |
2.14 |
-0.5 |
| PK |
400.0 |
2.14 |
-0.25 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
-0.5 |
| PK |
1600.0 |
2.14 |
-0.75 |
| PK |
2500.0 |
2.14 |
-0.5 |
| PK |
4000.0 |
2.14 |
0.25 |
| PK |
6300.0 |
2.14 |
-0.75 |
| PK |
10000.0 |
2.14 |
0.0 |
| PK |
16000.0 |
2.14 |
0.75 |
|
Download
|
This EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.9dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.25 |
| PK |
80.0 |
4.32 |
-0.25 |
| PK |
100.0 |
4.32 |
-0.25 |
| PK |
125.0 |
4.32 |
-0.25 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
-0.25 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.25 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
-0.5 |
| PK |
2000.0 |
4.32 |
0.5 |
| PK |
2500.0 |
4.32 |
0.5 |
| PK |
3150.0 |
4.32 |
0.75 |
| PK |
4000.0 |
4.32 |
0.25 |
| PK |
5000.0 |
4.32 |
0.25 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
0.5 |
| PK |
10000.0 |
4.32 |
0.25 |
| PK |
12000.0 |
4.32 |
0.5 |
| PK |
16000.0 |
4.32 |
0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
This EQ is designed for a 31 bands graphical EQ.
EQ
Target v.s. EQ
Histogram of errors
Listening Window (fullrange)
Predicted In-Room Response (fullrange)
Comparison betweens various EQs
|
