We have multiple measurements for this speaker. Click
here to
see the default one (which is higher quality if we have one
measurement better than the others).
- Quality of the measurement data is high .
- Origin of the data is ErinsAudioCorner .
- Format of the data is generated by a Klippel NFS .
- -3dB (resp. -6db) point v.s. reference is at 51.3Hz (resp. 26.4Hz).
- Reference level is normalised to -0.0dB computed over the frequency range [300.0Hz, 5000.0Hz].
- Frequency deviation is 2.2dB over the same frequency range.
- Directivity
- Horizontal directivity is (-50.0°, 50.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Vertical directivity is (-30.0°, 20.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 6.5
and would be 7.6 with a
perfect subwoofer.
- Details: NBD: ON 0.42, LW 0.33, SP 0.29, PIR 0.27; SM: SP0.87, PIR0.74; LFQ 1.78, LFX 24Hz
- Tonality (Preference) Score is 7.3
with an EQ and would be 8.1 with a
perfect subwoofer and the same EQ.
- Details: NBD: ON 0.42, LW 0.34, SP 0.29, PIR 0.26; SM: SP0.97, PIR0.96; LFQ 1.78, LFX 21Hz
- Tonality (Preference) Score is 6.5
and would be 7.6 with a
perfect subwoofer.
- Link to original Review: eac review. .
