What we know about the measurement:
Quality of the measurement data is
high .
Origin of the data is ASR.
Format of the data is
generated by a Klippel NFS
.
-3dB (resp. -6db) point v.s. reference is at 94.8Hz (resp. 62.6Hz).
Reference level is normalised to 0.4dB
computed over the frequency range [300.0Hz,
5000.0Hz].
Frequency deviation is 3.8dB over the same frequency range.
Directivity
Horizontal directivity
is (-60.0°, 60.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Vertical directivity
is (-20.0°, 40.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Tonality (Preference) Score
Tonality (Preference) Score is 3.08
and would be 5.82 with a
perfect subwoofer.
Details:
NBD: ON 0.567,
LW 0.506, SP
0.394, PIR
0.43; SM:
SP0.753,
PIR0.363; LFQ
0.383, LFX 62Hz
Tonality (Preference) Score is 5.71
with an EQ and would be 8.07 with a
perfect subwoofer and the same EQ.
Details:
NBD: ON 0.388,
LW 0.343, SP
0.336, PIR
0.272; SM:
SP0.956,
PIR0.933; LFQ 0.383, LFX 50Hz
Link to Original review .
AutomaticEQ (IIR)
Set preamp gain to: -2.8dB .
Type
Freq
Q
Gain
3
52.0
0.64
2.79
3
621.0
2.35
-1.33
3
2094.0
2.96
2.99
3
3525.0
2.13
-1.1
3
6361.0
1.21
-3.27
3
8397.0
1.89
2.73
3
12301.0
1.24
-3.88
Download
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
maiky76@ASR LW (IIR)
Set preamp gain to: -3.0dB .
Type
Freq
Q
Gain
1
56.46
1.35
0.0
3
118.83
1.64
-1.26
3
625.5
1.42
-1.82
3
1298.24
4.89
-1.2
3
2102.22
3.93
3.24
3
3860.8
1.62
-2.46
3
6314.2
3.59
-2.66
3
13434.58
4.27
-2.85
Download
These EQ is designed by ASR member maiky76. These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
maiky76@ASR (IIR)
Set preamp gain to: -3.0dB .
Type
Freq
Q
Gain
1
56.46
1.35
0.0
3
119.91
1.54
-1.26
3
608.5
1.26
-2.14
3
1299.74
4.95
-1.94
3
2060.46
3.62
3.02
3
3821.26
1.24
-2.89
3
6313.2
2.54
-2.88
3
12877.1
2.82
-4.27
Download
These EQ is designed by ASR member maiky76. These EQ optimise the Harman score and is a good start for far field listening like in your living room.
Graphic EQ 15 bands
Set preamp gain to: -0.7dB .
Type
Freq
Q
Gain
3
25.0
2.14
0.5
3
40.0
2.14
0.5
3
63.0
2.14
0.5
3
100.0
2.14
0.5
3
160.0
2.14
0.25
3
250.0
2.14
0.25
3
400.0
2.14
0.0
3
630.0
2.14
-0.5
3
1000.0
2.14
-0.25
3
1600.0
2.14
0.0
3
2500.0
2.14
0.0
3
4000.0
2.14
-0.75
3
6300.0
2.14
-1.0
3
10000.0
2.14
-0.25
3
16000.0
2.14
-0.25
Download
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
Set preamp gain to: -0.4dB .
Type
Freq
Q
Gain
3
20.0
4.32
0.0
3
25.0
4.32
0.25
3
31.0
4.32
0.25
3
40.0
4.32
0.25
3
50.0
4.32
0.25
3
63.0
4.32
0.25
3
80.0
4.32
0.25
3
100.0
4.32
0.25
3
125.0
4.32
0.25
3
160.0
4.32
0.0
3
200.0
4.32
0.0
3
250.0
4.32
0.0
3
315.0
4.32
0.0
3
400.0
4.32
0.0
3
500.0
4.32
-0.25
3
630.0
4.32
-0.25
3
800.0
4.32
-0.25
3
1000.0
4.32
-0.25
3
1250.0
4.32
-0.25
3
1600.0
4.32
0.0
3
2000.0
4.32
0.25
3
2500.0
4.32
0.0
3
3150.0
4.32
-0.25
3
4000.0
4.32
-0.25
3
5000.0
4.32
-0.5
3
6300.0
4.32
-0.5
3
8000.0
4.32
-0.25
3
10000.0
4.32
-0.5
3
12000.0
4.32
-0.75
3
16000.0
4.32
-0.25
3
20000.0
4.32
0.0
Download
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
