What we know about the measurement:
- Quality of the measurement data is
low.
-
Origin of the data is Misc.
-
Format of the data is
a scanned image
.
-
Sensitivity: 87.1dB (avg. 100Hz-1kHz for 2.83V estimated at 1m)
-
-3dB (resp. -6db) point v.s. reference is at 69.0Hz (resp. 66.2Hz).
-
Reference level is normalised to 0.5dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.8dB over the same frequency range.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for inwall speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is 1.92
and would be 4.67 with a
perfect subwoofer.
- Details:
NBD: ON 0.787,
LW 0.628, SP
0.616, PIR
0.579; SM:
SP0.399,
PIR0.297; LFQ
0.158, LFX 63Hz
- Tonality (Preference) Score is 4.71
with an EQ and would be 7.35 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.615,
LW 0.377, SP
0.354, PIR
0.275; SM:
SP0.812,
PIR0.871; LFQ 0.158, LFX 59Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -1.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
62.0 |
2.17 |
2.97 |
| 3 |
98.0 |
2.55 |
-6.49 |
| 3 |
130.0 |
2.98 |
-5.98 |
| 3 |
197.0 |
1.01 |
-4.57 |
| 3 |
560.0 |
2.87 |
1.69 |
| 3 |
6144.0 |
1.71 |
-1.51 |
| 3 |
11882.0 |
0.92 |
-8.89 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.25 |
| 3 |
40.0 |
2.14 |
0.25 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
-1.25 |
| 3 |
160.0 |
2.14 |
-0.75 |
| 3 |
250.0 |
2.14 |
-0.5 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.25 |
| 3 |
1000.0 |
2.14 |
0.0 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
0.25 |
| 3 |
4000.0 |
2.14 |
0.25 |
| 3 |
6300.0 |
2.14 |
0.0 |
| 3 |
10000.0 |
2.14 |
-0.5 |
| 3 |
16000.0 |
2.14 |
-0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.25 |
| 3 |
31.0 |
4.32 |
0.25 |
| 3 |
40.0 |
4.32 |
0.25 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
-0.5 |
| 3 |
100.0 |
4.32 |
-1.0 |
| 3 |
125.0 |
4.32 |
-1.25 |
| 3 |
160.0 |
4.32 |
-0.75 |
| 3 |
200.0 |
4.32 |
-0.75 |
| 3 |
250.0 |
4.32 |
-0.5 |
| 3 |
315.0 |
4.32 |
-0.5 |
| 3 |
400.0 |
4.32 |
-0.25 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
-0.25 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
-0.25 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
0.0 |
| 3 |
3150.0 |
4.32 |
0.0 |
| 3 |
4000.0 |
4.32 |
-0.25 |
| 3 |
5000.0 |
4.32 |
-0.25 |
| 3 |
6300.0 |
4.32 |
-0.5 |
| 3 |
8000.0 |
4.32 |
-0.5 |
| 3 |
10000.0 |
4.32 |
-0.75 |
| 3 |
12000.0 |
4.32 |
-1.0 |
| 3 |
16000.0 |
4.32 |
-0.25 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
