What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 87.8dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 46.9Hz (resp. 41.0Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 4.3dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.39
and would be 6.34 with a
perfect subwoofer.
- Details:
NBD: ON 0.599,
LW 0.547, SP
0.412, PIR
0.423; SM:
SP0.814,
PIR0.611; LFQ
0.833, LFX 41Hz
- Tonality (Preference) Score is 6.24
with an EQ and would be 7.98 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.42,
LW 0.369, SP
0.314, PIR
0.264; SM:
SP0.965,
PIR0.92; LFQ 0.833, LFX 36Hz
- Link to Original review.
AutomaticEQ (IIR)
|
Set preamp gain to: -2.6dB.
|
Type |
Freq |
Q |
Gain |
3 |
36.0 |
0.6 |
2.43 |
3 |
190.0 |
0.52 |
-1.95 |
3 |
356.0 |
2.94 |
0.79 |
3 |
792.0 |
1.28 |
-2.28 |
3 |
1046.0 |
3.0 |
3.0 |
3 |
2670.0 |
1.89 |
3.0 |
3 |
10341.0 |
0.69 |
-2.54 |
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
flipflop@ASR (IIR)
|
Set preamp gain to: -5.5dB.
|
Type |
Freq |
Q |
Gain |
3 |
415.0 |
5.0 |
0.4 |
3 |
716.0 |
2.668 |
-1.4 |
3 |
854.0 |
5.0 |
-1.4 |
3 |
1089.0 |
5.0 |
5.2 |
3 |
1218.0 |
5.0 |
-3.0 |
3 |
1422.0 |
10.0 |
0.7 |
3 |
1544.0 |
12.0 |
-1.2 |
3 |
1615.0 |
2.988 |
-2.6 |
3 |
1695.0 |
10.0 |
0.8 |
3 |
1758.0 |
1.0 |
3.1 |
3 |
1875.0 |
18.0 |
-0.7 |
3 |
2217.0 |
15.0 |
-1.4 |
3 |
2412.0 |
13.0 |
1.7 |
3 |
2590.0 |
18.0 |
-1.1 |
3 |
2631.0 |
1.012 |
-6.5 |
3 |
2931.0 |
1.092 |
11.6 |
3 |
3608.0 |
2.691 |
-4.8 |
3 |
10315.0 |
1.0 |
-1.9 |
3 |
10820.0 |
9.0 |
0.6 |
3 |
15540.0 |
4.0 |
-0.4 |
Download
|
These EQ is designed by ASR member flipflop.
Graphic EQ 15 bands
|
Set preamp gain to: -1.1dB.
|
Type |
Freq |
Q |
Gain |
3 |
25.0 |
2.14 |
0.5 |
3 |
40.0 |
2.14 |
0.5 |
3 |
63.0 |
2.14 |
0.0 |
3 |
100.0 |
2.14 |
0.0 |
3 |
160.0 |
2.14 |
-0.25 |
3 |
250.0 |
2.14 |
-0.25 |
3 |
400.0 |
2.14 |
0.0 |
3 |
630.0 |
2.14 |
-0.25 |
3 |
1000.0 |
2.14 |
0.5 |
3 |
1600.0 |
2.14 |
0.25 |
3 |
2500.0 |
2.14 |
1.0 |
3 |
4000.0 |
2.14 |
0.25 |
3 |
6300.0 |
2.14 |
0.25 |
3 |
10000.0 |
2.14 |
0.0 |
3 |
16000.0 |
2.14 |
0.25 |
Download
|
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
|
Set preamp gain to: -0.6dB.
|
Type |
Freq |
Q |
Gain |
3 |
20.0 |
4.32 |
0.0 |
3 |
25.0 |
4.32 |
0.25 |
3 |
31.0 |
4.32 |
0.25 |
3 |
40.0 |
4.32 |
0.25 |
3 |
50.0 |
4.32 |
0.25 |
3 |
63.0 |
4.32 |
0.0 |
3 |
80.0 |
4.32 |
0.0 |
3 |
100.0 |
4.32 |
0.0 |
3 |
125.0 |
4.32 |
-0.25 |
3 |
160.0 |
4.32 |
-0.25 |
3 |
200.0 |
4.32 |
-0.25 |
3 |
250.0 |
4.32 |
-0.25 |
3 |
315.0 |
4.32 |
-0.25 |
3 |
400.0 |
4.32 |
0.0 |
3 |
500.0 |
4.32 |
-0.25 |
3 |
630.0 |
4.32 |
-0.25 |
3 |
800.0 |
4.32 |
-0.25 |
3 |
1000.0 |
4.32 |
0.25 |
3 |
1250.0 |
4.32 |
0.0 |
3 |
1600.0 |
4.32 |
0.0 |
3 |
2000.0 |
4.32 |
0.25 |
3 |
2500.0 |
4.32 |
0.5 |
3 |
3150.0 |
4.32 |
0.25 |
3 |
4000.0 |
4.32 |
0.0 |
3 |
5000.0 |
4.32 |
0.0 |
3 |
6300.0 |
4.32 |
0.0 |
3 |
8000.0 |
4.32 |
-0.25 |
3 |
10000.0 |
4.32 |
-0.25 |
3 |
12000.0 |
4.32 |
-0.25 |
3 |
16000.0 |
4.32 |
-0.25 |
3 |
20000.0 |
4.32 |
0.0 |
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
