What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 85.1dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 82.0Hz (resp. 63.0Hz).
-
Reference level is normalised to -0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.2dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-70.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.23
and would be 5.89 with a
perfect subwoofer.
- Details:
NBD: ON 0.618,
LW 0.49, SP
0.386, PIR
0.415; SM:
SP0.763,
PIR0.426; LFQ
0.317, LFX 60Hz
- Tonality (Preference) Score is 5.69
with an EQ and would be 8.06 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.436,
LW 0.343, SP
0.34, PIR
0.262; SM:
SP0.97,
PIR0.968; LFQ 0.317, LFX 51Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| 5 |
96.0 |
0.73 |
2.98 |
| 3 |
309.0 |
2.01 |
1.01 |
| 3 |
668.0 |
2.04 |
1.47 |
| 3 |
965.0 |
2.9 |
-2.66 |
| 3 |
1541.0 |
1.58 |
0.88 |
| 3 |
2813.0 |
2.52 |
2.55 |
| 3 |
5677.0 |
1.47 |
-2.91 |
| 3 |
10713.0 |
2.37 |
-2.39 |
| 3 |
13537.0 |
1.19 |
-2.6 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -2.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
619.0 |
5.0 |
0.9 |
| 3 |
748.0 |
5.0 |
-2.1 |
| 3 |
775.0 |
5.0 |
2.6 |
| 3 |
937.0 |
3.729 |
-3.7 |
| 3 |
1356.0 |
5.0 |
-2.4 |
| 3 |
1541.0 |
5.0 |
2.2 |
| 3 |
1703.0 |
5.0 |
-2.1 |
| 3 |
2871.0 |
5.0 |
6.9 |
| 3 |
2988.0 |
4.932 |
-9.9 |
| 3 |
3115.0 |
5.0 |
5.8 |
| 3 |
3885.0 |
8.0 |
-1.0 |
| 3 |
4625.0 |
5.0 |
0.6 |
| 3 |
5232.0 |
5.0 |
-1.8 |
| 3 |
5711.0 |
5.0 |
-2.1 |
| 3 |
8083.0 |
5.0 |
0.8 |
| 3 |
8748.0 |
5.0 |
2.1 |
| 3 |
12321.0 |
5.0 |
4.2 |
| 3 |
12870.0 |
1.446 |
-10.7 |
| 3 |
13527.0 |
5.0 |
4.6 |
| 3 |
16700.0 |
3.3 |
-1.9 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.5 |
| 3 |
40.0 |
2.14 |
0.5 |
| 3 |
63.0 |
2.14 |
0.5 |
| 3 |
100.0 |
2.14 |
0.25 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
-0.5 |
| 3 |
1600.0 |
2.14 |
-0.25 |
| 3 |
2500.0 |
2.14 |
0.0 |
| 3 |
4000.0 |
2.14 |
-0.25 |
| 3 |
6300.0 |
2.14 |
-0.5 |
| 3 |
10000.0 |
2.14 |
-0.75 |
| 3 |
16000.0 |
2.14 |
-0.75 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.5 |
| 3 |
31.0 |
4.32 |
0.5 |
| 3 |
40.0 |
4.32 |
0.5 |
| 3 |
50.0 |
4.32 |
0.5 |
| 3 |
63.0 |
4.32 |
0.5 |
| 3 |
80.0 |
4.32 |
0.5 |
| 3 |
100.0 |
4.32 |
0.25 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
-0.5 |
| 3 |
1250.0 |
4.32 |
-0.25 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
0.25 |
| 3 |
3150.0 |
4.32 |
0.25 |
| 3 |
4000.0 |
4.32 |
-0.25 |
| 3 |
5000.0 |
4.32 |
-0.25 |
| 3 |
6300.0 |
4.32 |
-0.25 |
| 3 |
8000.0 |
4.32 |
0.0 |
| 3 |
10000.0 |
4.32 |
-0.5 |
| 3 |
12000.0 |
4.32 |
-0.75 |
| 3 |
16000.0 |
4.32 |
-0.5 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
