What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ErinsAudioCorner.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 54.2Hz (resp. 51.3Hz).
-
Reference level is normalised to -0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 7.1dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (0.0°, 0.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-50.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for omnidirectional speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is 0.67
and would be 3.08 with a
perfect subwoofer.
- Details:
NBD: ON 1.26,
LW 0.929, SP
0.609, PIR
0.659; SM:
SP0.223,
PIR0.221; LFQ
0.259, LFX 52Hz
- Tonality (Preference) Score is 3.58
with an EQ and would be 6.05 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.917,
LW 0.613, SP
0.408, PIR
0.385; SM:
SP0.712,
PIR0.779; LFQ 0.259, LFX 54Hz
-
Link to original Review: eac review.
Links to other reviews: asr review
.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -4.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
93.0 |
1.3 |
-3.0 |
| 3 |
121.0 |
0.91 |
-2.97 |
| 3 |
143.0 |
0.7 |
-2.88 |
| 3 |
1032.0 |
1.99 |
2.99 |
| 3 |
1704.0 |
2.97 |
-2.95 |
| 3 |
3438.0 |
2.97 |
-2.26 |
| 3 |
4202.0 |
2.86 |
2.87 |
| 3 |
9372.0 |
2.68 |
2.78 |
| 3 |
16000.0 |
0.34 |
2.14 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.25 |
| 3 |
40.0 |
2.14 |
0.25 |
| 3 |
63.0 |
2.14 |
-0.5 |
| 3 |
100.0 |
2.14 |
-1.0 |
| 3 |
160.0 |
2.14 |
-0.75 |
| 3 |
250.0 |
2.14 |
-0.5 |
| 3 |
400.0 |
2.14 |
-0.25 |
| 3 |
630.0 |
2.14 |
-0.25 |
| 3 |
1000.0 |
2.14 |
0.0 |
| 3 |
1600.0 |
2.14 |
-0.75 |
| 3 |
2500.0 |
2.14 |
-0.75 |
| 3 |
4000.0 |
2.14 |
-0.5 |
| 3 |
6300.0 |
2.14 |
-0.75 |
| 3 |
10000.0 |
2.14 |
-0.5 |
| 3 |
16000.0 |
2.14 |
-0.75 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.25 |
| 3 |
31.0 |
4.32 |
0.25 |
| 3 |
40.0 |
4.32 |
0.25 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
-0.5 |
| 3 |
80.0 |
4.32 |
-1.0 |
| 3 |
100.0 |
4.32 |
-1.0 |
| 3 |
125.0 |
4.32 |
-0.75 |
| 3 |
160.0 |
4.32 |
-0.75 |
| 3 |
200.0 |
4.32 |
-0.5 |
| 3 |
250.0 |
4.32 |
-0.5 |
| 3 |
315.0 |
4.32 |
-0.25 |
| 3 |
400.0 |
4.32 |
-0.25 |
| 3 |
500.0 |
4.32 |
-0.25 |
| 3 |
630.0 |
4.32 |
-0.25 |
| 3 |
800.0 |
4.32 |
-0.25 |
| 3 |
1000.0 |
4.32 |
0.0 |
| 3 |
1250.0 |
4.32 |
-0.25 |
| 3 |
1600.0 |
4.32 |
-0.75 |
| 3 |
2000.0 |
4.32 |
-0.5 |
| 3 |
2500.0 |
4.32 |
-0.75 |
| 3 |
3150.0 |
4.32 |
-0.75 |
| 3 |
4000.0 |
4.32 |
-0.5 |
| 3 |
5000.0 |
4.32 |
-0.5 |
| 3 |
6300.0 |
4.32 |
-0.5 |
| 3 |
8000.0 |
4.32 |
-0.75 |
| 3 |
10000.0 |
4.32 |
-0.5 |
| 3 |
12000.0 |
4.32 |
-0.75 |
| 3 |
16000.0 |
4.32 |
-0.5 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
