What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is BiAmp.
-
Format of the data is
a GLL file
.
-
Sensitivity:
-
Sensitivity: 85.5dB (avg. 100Hz-1kHz for 2.83V estimated at 1m).
-
Sensitivity: 65.5dB computed at the measurement distance (10.0m) over the same frequency range.
-
-3dB (resp. -6db) point v.s. reference is at 118.0Hz (resp. 97.5Hz).
-
Reference level is normalised to 0.5dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 6.2dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is -1.05
and would be 2.56 with a
perfect subwoofer.
- Details:
NBD: ON 0.969,
LW 0.884, SP
0.979, PIR
0.93; SM:
SP0.345,
PIR0.032; LFQ
1.135, LFX 100Hz
- Tonality (Preference) Score is 2.09
with an EQ and would be 5.35 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.817,
LW 0.741, SP
0.757, PIR
0.72; SM:
SP0.877,
PIR0.8; LFQ 1.024, LFX 82Hz
-
Note: data computed at 2 meters..
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
95.0 |
2.99 |
3.0 |
| PK |
395.0 |
3.0 |
0.79 |
| PK |
792.0 |
0.28 |
2.44 |
| PK |
1760.0 |
1.76 |
-7.87 |
| PK |
4342.0 |
2.18 |
-3.91 |
| PK |
6361.0 |
3.0 |
-4.61 |
| PK |
10341.0 |
1.89 |
-6.5 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.5 |
| PK |
100.0 |
2.14 |
0.5 |
| PK |
160.0 |
2.14 |
0.25 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.5 |
| PK |
630.0 |
2.14 |
0.25 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
-1.0 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.75 |
| PK |
10000.0 |
2.14 |
-0.75 |
| PK |
16000.0 |
2.14 |
0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.25 |
| PK |
80.0 |
4.32 |
0.25 |
| PK |
100.0 |
4.32 |
0.25 |
| PK |
125.0 |
4.32 |
0.25 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.25 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.25 |
| PK |
400.0 |
4.32 |
0.5 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
0.25 |
| PK |
800.0 |
4.32 |
0.5 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.25 |
| PK |
1600.0 |
4.32 |
-0.75 |
| PK |
2000.0 |
4.32 |
-0.75 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
-0.5 |
| PK |
8000.0 |
4.32 |
-0.25 |
| PK |
10000.0 |
4.32 |
-0.5 |
| PK |
12000.0 |
4.32 |
-0.5 |
| PK |
16000.0 |
4.32 |
0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
