What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 80.6dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 95.2Hz (resp. 71.8Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 5.2dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 1.19
and would be 4.26 with a
perfect subwoofer.
- Details:
NBD: ON 0.863,
LW 0.678, SP
0.597, PIR
0.609; SM:
SP0.622,
PIR0.236; LFQ
0.608, LFX 74Hz
- Tonality (Preference) Score is 3.87
with an EQ and would be 6.39 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.654,
LW 0.568, SP
0.534, PIR
0.525; SM:
SP0.901,
PIR0.821; LFQ 0.524, LFX 55Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
72.0 |
0.57 |
2.99 |
| PK |
155.0 |
1.51 |
-2.75 |
| PK |
439.0 |
1.1 |
1.41 |
| PK |
1642.0 |
3.0 |
-3.17 |
| PK |
3177.0 |
2.99 |
-1.43 |
| PK |
6585.0 |
2.09 |
-3.44 |
| PK |
12301.0 |
0.75 |
-4.11 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -3.5dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
405.0 |
4.0 |
0.7 |
| PK |
524.0 |
7.0 |
3.0 |
| PK |
590.0 |
8.5 |
-5.6 |
| PK |
714.0 |
5.0 |
-0.9 |
| PK |
1019.0 |
5.0 |
-7.2 |
| PK |
1088.0 |
5.0 |
10.0 |
| PK |
1256.0 |
5.0 |
-4.9 |
| PK |
1455.0 |
4.999 |
10.0 |
| PK |
1536.0 |
5.0 |
-12.3 |
| PK |
1682.0 |
4.998 |
3.3 |
| PK |
1835.0 |
5.0 |
-5.2 |
| PK |
1991.0 |
5.0 |
1.4 |
| PK |
2170.0 |
17.0 |
-0.8 |
| PK |
3124.0 |
5.0 |
-1.6 |
| PK |
5781.0 |
1.012 |
-1.4 |
| PK |
6153.0 |
5.0 |
-1.9 |
| PK |
9102.0 |
1.856 |
-3.2 |
| PK |
12266.0 |
5.0 |
-2.9 |
| PK |
13500.0 |
7.0 |
-0.9 |
| PK |
15181.0 |
3.162 |
-3.2 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.5 |
| PK |
100.0 |
2.14 |
0.25 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.25 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
-0.5 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
0.0 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
-0.5 |
| PK |
16000.0 |
2.14 |
-0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.5 |
| PK |
80.0 |
4.32 |
0.5 |
| PK |
100.0 |
4.32 |
0.25 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.25 |
| PK |
400.0 |
4.32 |
0.25 |
| PK |
500.0 |
4.32 |
0.5 |
| PK |
630.0 |
4.32 |
-0.5 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
0.0 |
| PK |
1600.0 |
4.32 |
-0.5 |
| PK |
2000.0 |
4.32 |
-0.25 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
-0.25 |
| PK |
4000.0 |
4.32 |
0.0 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
-0.5 |
| PK |
8000.0 |
4.32 |
-0.25 |
| PK |
10000.0 |
4.32 |
-0.5 |
| PK |
12000.0 |
4.32 |
-0.5 |
| PK |
16000.0 |
4.32 |
-0.25 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
