We have multiple measurements for this speaker. Click here to see the default one (which is higher quality if we have one measurement better than the others).
- Quality of the measurement data is high.
- Origin of the data is ErinsAudioCorner.
- Format of the data is generated by a Klippel NFS .
- -3dB (resp. -6db) point v.s. reference is at 82.0Hz (resp. 63.0Hz).
- Reference level is normalised to 0.3dB computed over the frequency range [300.0Hz, 5000.0Hz].
- Frequency deviation is 1.9dB over the same frequency range.
- Directivity
- Horizontal directivity is (-50.0°, 50.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Vertical directivity is (-40.0°, 20.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.69
and would be 6.48 with a
perfect subwoofer.
- Details: NBD: ON 0.395, LW 0.369, SP 0.384, PIR 0.325; SM: SP0.701, PIR0.327; LFQ 1.053, LFX 64Hz
- Tonality (Preference) Score is 5.88
with an EQ and would be 7.83 with a
perfect subwoofer and the same EQ.
- Details: NBD: ON 0.333, LW 0.325, SP 0.356, PIR 0.282; SM: SP0.894, PIR0.787; LFQ 0.94, LFX 41Hz
- Tonality (Preference) Score is 3.69
and would be 6.48 with a
perfect subwoofer.
- Link to Original review.
- Note: This version had a bad tweeter..
