We have multiple measurements for this speaker. Click here to see the default one (which is higher quality if we have one measurement better than the others).
- Quality of the measurement data is high.
- Origin of the data is Alcons Audio.
- Format of the data is a set of 36 horizontal and 36 vertical measurements .
- -3dB (resp. -6db) point v.s. reference is at 87.5Hz (resp. 85.0Hz).
- Reference level is normalised to -0.2dB computed over the frequency range [300.0Hz, 5000.0Hz].
- Frequency deviation is 2.9dB over the same frequency range.
- Directivity
- Horizontal directivity is (-50.0°, 50.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Vertical directivity is (-40.0°, 10.0°) between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.58
and would be 6.84 with a
perfect subwoofer.
- Details: NBD: ON 0.499, LW 0.483, SP 0.594, PIR 0.536; SM: SP0.922, PIR0.862; LFQ 0.823, LFX 82Hz
- Tonality (Preference) Score is 4.34
with an EQ and would be 7.65 with a
perfect subwoofer and the same EQ.
- Details: NBD: ON 0.37, LW 0.317, SP 0.469, PIR 0.368; SM: SP0.94, PIR0.86; LFQ 0.823, LFX 85Hz
- Tonality (Preference) Score is 3.58
and would be 6.84 with a
perfect subwoofer.
- Link to original Review: psw review. Links to other reviews: axp review .
-
Vendor specifications:
- Dispersion: 120° horizontal and 15° vertical.
- Sensitivity 97 dB
- Impedance 4 Ohm
- SPL
- peak: 131 dB
- Size
- Width 150mm
- Height 742mm
- Depth 150 mm)
- Weight 12 kg
