What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 39.6Hz (resp. 36.6Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.0dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.65
and would be 6.31 with a
perfect subwoofer.
- Details:
NBD: ON 0.511,
LW 0.507, SP
0.566, PIR
0.502; SM:
SP0.817,
PIR0.605; LFQ
0.774, LFX 35Hz
- Tonality (Preference) Score is 6.34
with an EQ and would be 7.83 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.397,
LW 0.381, SP
0.39, PIR
0.329; SM:
SP0.95,
PIR0.917; LFQ 0.887, LFX 32Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -1.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
36.0 |
2.1 |
1.81 |
| PK |
178.0 |
2.93 |
0.46 |
| PK |
1121.0 |
2.97 |
-2.08 |
| PK |
2245.0 |
1.26 |
3.0 |
| PK |
4654.0 |
2.99 |
2.46 |
| PK |
6144.0 |
0.56 |
-4.53 |
| PK |
12301.0 |
2.84 |
-0.74 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -2.5dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
404.0 |
13.0 |
0.9 |
| PK |
576.0 |
10.0 |
-1.8 |
| PK |
1100.0 |
4.0 |
-2.1 |
| PK |
1631.0 |
15.0 |
-1.4 |
| PK |
1860.0 |
10.0 |
-1.0 |
| PK |
2010.0 |
2.3 |
3.3 |
| PK |
2205.0 |
9.0 |
-2.7 |
| PK |
2565.0 |
15.0 |
-1.1 |
| PK |
2765.0 |
12.0 |
1.5 |
| PK |
3070.0 |
8.0 |
-1.0 |
| PK |
3635.0 |
15.0 |
-1.3 |
| PK |
4140.0 |
6.5 |
-2.5 |
| PK |
4600.0 |
12.0 |
3.8 |
| PK |
5650.0 |
20.0 |
-0.9 |
| PK |
6100.0 |
7.0 |
-1.4 |
| PK |
6580.0 |
10.0 |
0.9 |
| PK |
8100.0 |
1.5 |
-2.7 |
| PK |
12070.0 |
3.0 |
-1.4 |
| PK |
13850.0 |
4.0 |
1.1 |
| PK |
15700.0 |
4.5 |
-1.2 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.25 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.0 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
0.0 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
0.25 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
-0.5 |
| PK |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.0 |
| PK |
63.0 |
4.32 |
0.0 |
| PK |
80.0 |
4.32 |
0.0 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
-0.25 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
-0.25 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.25 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.25 |
| PK |
6300.0 |
4.32 |
-0.5 |
| PK |
8000.0 |
4.32 |
-0.5 |
| PK |
10000.0 |
4.32 |
-0.5 |
| PK |
12000.0 |
4.32 |
-0.25 |
| PK |
16000.0 |
4.32 |
0.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
