What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 58.6Hz (resp. 51.3Hz).
-
Reference level is normalised to 0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.0dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.06
and would be 6.42 with a
perfect subwoofer.
- Details:
NBD: ON 0.435,
LW 0.423, SP
0.441, PIR
0.421; SM:
SP0.866,
PIR0.47; LFQ
0.474, LFX 51Hz
- Tonality (Preference) Score is 6.01
with an EQ and would be 8.08 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.353,
LW 0.34, SP
0.326, PIR
0.3; SM:
SP0.978,
PIR0.939; LFQ 0.532, LFX 43Hz
- Link to Original review.
AutomaticEQ (IIR)
|
Set preamp gain to: -3.0dB.
|
Type |
Freq |
Q |
Gain |
PK |
47.0 |
1.58 |
2.97 |
PK |
270.0 |
0.92 |
1.41 |
PK |
792.0 |
1.59 |
2.98 |
PK |
820.0 |
3.0 |
-4.69 |
PK |
3405.0 |
1.46 |
2.99 |
PK |
6144.0 |
0.52 |
-4.04 |
PK |
14134.0 |
2.38 |
-1.32 |
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
flipflop@ASR (IIR)
|
Set preamp gain to: -0.3dB.
|
Type |
Freq |
Q |
Gain |
PK |
449.0 |
8.0 |
-0.6 |
PK |
556.0 |
10.0 |
-1.4 |
PK |
618.0 |
19.0 |
-0.9 |
PK |
670.0 |
18.0 |
1.5 |
PK |
729.0 |
9.0 |
-2.3 |
PK |
831.0 |
7.0 |
-2.2 |
PK |
947.0 |
10.0 |
-1.4 |
PK |
1040.0 |
16.0 |
1.4 |
PK |
1120.0 |
18.0 |
-1.4 |
PK |
1345.0 |
3.7 |
-2.9 |
PK |
1718.0 |
8.0 |
-1.8 |
PK |
2070.0 |
15.0 |
-1.1 |
PK |
2280.0 |
20.0 |
0.8 |
PK |
2492.0 |
14.0 |
-1.6 |
PK |
2955.0 |
13.0 |
-1.3 |
HS |
3000.0 |
1.5772935127949521 |
-4.8 |
PK |
3305.0 |
6.2 |
2.2 |
PK |
4570.0 |
7.0 |
3.4 |
PK |
5250.0 |
3.3 |
-1.3 |
PK |
16800.0 |
2.8 |
2.9 |
Download
|
These EQ is designed by ASR member flipflop.
Graphic EQ 15 bands
|
Set preamp gain to: -0.6dB.
|
Type |
Freq |
Q |
Gain |
PK |
25.0 |
2.14 |
0.5 |
PK |
40.0 |
2.14 |
0.5 |
PK |
63.0 |
2.14 |
0.25 |
PK |
100.0 |
2.14 |
0.0 |
PK |
160.0 |
2.14 |
0.0 |
PK |
250.0 |
2.14 |
0.25 |
PK |
400.0 |
2.14 |
0.25 |
PK |
630.0 |
2.14 |
0.0 |
PK |
1000.0 |
2.14 |
0.0 |
PK |
1600.0 |
2.14 |
0.0 |
PK |
2500.0 |
2.14 |
-0.25 |
PK |
4000.0 |
2.14 |
-0.25 |
PK |
6300.0 |
2.14 |
-0.5 |
PK |
10000.0 |
2.14 |
-0.5 |
PK |
16000.0 |
2.14 |
0.0 |
Download
|
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
|
Set preamp gain to: -0.7dB.
|
Type |
Freq |
Q |
Gain |
PK |
20.0 |
4.32 |
0.0 |
PK |
25.0 |
4.32 |
0.5 |
PK |
31.0 |
4.32 |
0.5 |
PK |
40.0 |
4.32 |
0.5 |
PK |
50.0 |
4.32 |
0.5 |
PK |
63.0 |
4.32 |
0.25 |
PK |
80.0 |
4.32 |
0.0 |
PK |
100.0 |
4.32 |
0.0 |
PK |
125.0 |
4.32 |
0.0 |
PK |
160.0 |
4.32 |
0.0 |
PK |
200.0 |
4.32 |
0.25 |
PK |
250.0 |
4.32 |
0.25 |
PK |
315.0 |
4.32 |
0.25 |
PK |
400.0 |
4.32 |
0.25 |
PK |
500.0 |
4.32 |
0.0 |
PK |
630.0 |
4.32 |
0.0 |
PK |
800.0 |
4.32 |
-0.25 |
PK |
1000.0 |
4.32 |
0.0 |
PK |
1250.0 |
4.32 |
-0.25 |
PK |
1600.0 |
4.32 |
0.0 |
PK |
2000.0 |
4.32 |
0.0 |
PK |
2500.0 |
4.32 |
-0.25 |
PK |
3150.0 |
4.32 |
0.0 |
PK |
4000.0 |
4.32 |
-0.25 |
PK |
5000.0 |
4.32 |
-0.5 |
PK |
6300.0 |
4.32 |
-0.5 |
PK |
8000.0 |
4.32 |
-0.5 |
PK |
10000.0 |
4.32 |
-0.5 |
PK |
12000.0 |
4.32 |
-0.5 |
PK |
16000.0 |
4.32 |
0.0 |
PK |
20000.0 |
4.32 |
0.0 |
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
