What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 52.7Hz (resp. 45.4Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.3dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-60.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.48
and would be 7.62 with a
perfect subwoofer.
- Details:
NBD: ON 0.338,
LW 0.319, SP
0.315, PIR
0.282; SM:
SP0.922,
PIR0.7; LFQ
0.746, LFX 45Hz
- Tonality (Preference) Score is 6.25
with an EQ and would be 8.26 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.334,
LW 0.309, SP
0.3, PIR
0.263; SM:
SP0.974,
PIR0.947; LFQ 0.746, LFX 42Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
52.0 |
0.64 |
2.21 |
| 3 |
280.0 |
0.91 |
1.15 |
| 3 |
447.0 |
1.55 |
1.28 |
| 3 |
625.0 |
2.08 |
-0.63 |
| 3 |
1948.0 |
2.88 |
1.78 |
| 3 |
3930.0 |
2.86 |
1.4 |
| 3 |
5135.0 |
0.58 |
-1.39 |
| 3 |
8199.0 |
1.05 |
0.5 |
| 3 |
11454.0 |
1.16 |
-0.5 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -0.8dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
340.0 |
10.0 |
0.8 |
| 3 |
400.0 |
15.0 |
0.7 |
| 3 |
485.0 |
10.0 |
1.5 |
| 3 |
597.0 |
5.0 |
-1.5 |
| 3 |
1049.0 |
1.0 |
-1.8 |
| 3 |
1370.0 |
20.0 |
-0.5 |
| 3 |
1660.0 |
20.0 |
0.8 |
| 3 |
2350.0 |
20.0 |
-1.2 |
| 3 |
2902.0 |
4.178 |
-1.1 |
| 3 |
3979.0 |
5.0 |
1.4 |
| 3 |
5886.0 |
5.0 |
3.1 |
| 3 |
6702.0 |
1.0 |
-3.8 |
| 3 |
7943.0 |
5.0 |
3.1 |
| 3 |
8825.0 |
5.0 |
-2.7 |
| 3 |
9458.0 |
5.0 |
2.8 |
| 3 |
10680.0 |
10.0 |
-0.7 |
| 3 |
11866.0 |
1.0 |
-1.8 |
| 3 |
11950.0 |
12.0 |
0.8 |
| 3 |
17828.0 |
5.0 |
-1.6 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.5 |
| 3 |
40.0 |
2.14 |
0.5 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
0.25 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.25 |
| 3 |
400.0 |
2.14 |
0.25 |
| 3 |
630.0 |
2.14 |
-0.25 |
| 3 |
1000.0 |
2.14 |
-0.25 |
| 3 |
1600.0 |
2.14 |
-0.25 |
| 3 |
2500.0 |
2.14 |
-0.25 |
| 3 |
4000.0 |
2.14 |
-0.25 |
| 3 |
6300.0 |
2.14 |
-0.5 |
| 3 |
10000.0 |
2.14 |
-0.5 |
| 3 |
16000.0 |
2.14 |
-0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.5 |
| 3 |
31.0 |
4.32 |
0.5 |
| 3 |
40.0 |
4.32 |
0.5 |
| 3 |
50.0 |
4.32 |
0.5 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
0.25 |
| 3 |
100.0 |
4.32 |
0.25 |
| 3 |
125.0 |
4.32 |
0.25 |
| 3 |
160.0 |
4.32 |
0.25 |
| 3 |
200.0 |
4.32 |
0.25 |
| 3 |
250.0 |
4.32 |
0.25 |
| 3 |
315.0 |
4.32 |
0.25 |
| 3 |
400.0 |
4.32 |
0.25 |
| 3 |
500.0 |
4.32 |
0.25 |
| 3 |
630.0 |
4.32 |
-0.25 |
| 3 |
800.0 |
4.32 |
0.0 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
-0.25 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
0.0 |
| 3 |
2500.0 |
4.32 |
-0.25 |
| 3 |
3150.0 |
4.32 |
-0.25 |
| 3 |
4000.0 |
4.32 |
0.0 |
| 3 |
5000.0 |
4.32 |
-0.25 |
| 3 |
6300.0 |
4.32 |
-0.25 |
| 3 |
8000.0 |
4.32 |
-0.25 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
-0.25 |
| 3 |
16000.0 |
4.32 |
-0.25 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
