What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is AIA Cinema.
-
Format of the data is
a scanned image
.
-
Sensitivity: 94.6dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 65.2Hz (resp. 60.5Hz).
-
Reference level is normalised to 0.6dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 1.6dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.43
and would be 7.07 with a
perfect subwoofer.
- Details:
NBD: ON 0.467,
LW 0.251, SP
0.458, PIR
0.355; SM:
SP0.772,
PIR0.699; LFQ
0.159, LFX 59Hz
- Tonality (Preference) Score is 5.6
with an EQ and would be 8.19 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.395,
LW 0.149, SP
0.333, PIR
0.213; SM:
SP0.889,
PIR0.92; LFQ 0.159, LFX 58Hz
-
Link to original Review: vendor review.
.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -1.6dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
65.0 |
0.4 |
1.52 |
| PK |
253.0 |
2.28 |
1.1 |
| PK |
478.0 |
2.84 |
0.79 |
| PK |
1442.0 |
2.97 |
1.02 |
| PK |
2153.0 |
2.98 |
2.82 |
| PK |
3930.0 |
2.17 |
2.49 |
| PK |
5310.0 |
0.37 |
-2.72 |
| PK |
7669.0 |
2.89 |
2.34 |
| PK |
13537.0 |
0.83 |
1.26 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.0 |
| PK |
40.0 |
2.14 |
0.25 |
| PK |
63.0 |
2.14 |
0.25 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
-0.25 |
| PK |
400.0 |
2.14 |
-0.25 |
| PK |
630.0 |
2.14 |
-0.5 |
| PK |
1000.0 |
2.14 |
-0.5 |
| PK |
1600.0 |
2.14 |
-0.25 |
| PK |
2500.0 |
2.14 |
-0.5 |
| PK |
4000.0 |
2.14 |
-0.5 |
| PK |
6300.0 |
2.14 |
-0.75 |
| PK |
10000.0 |
2.14 |
-0.75 |
| PK |
16000.0 |
2.14 |
-0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.0 |
| PK |
31.0 |
4.32 |
0.0 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.25 |
| PK |
80.0 |
4.32 |
0.0 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
-0.25 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
-0.25 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
-0.25 |
| PK |
1600.0 |
4.32 |
-0.25 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
-0.25 |
| PK |
3150.0 |
4.32 |
-0.25 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.5 |
| PK |
6300.0 |
4.32 |
-0.5 |
| PK |
8000.0 |
4.32 |
-0.25 |
| PK |
10000.0 |
4.32 |
-0.5 |
| PK |
12000.0 |
4.32 |
-0.25 |
| PK |
16000.0 |
4.32 |
0.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
