What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 87.9Hz (resp. 43.9Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.8dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-70.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.93
and would be 5.87 with a
perfect subwoofer.
- Details:
NBD: ON 0.585,
LW 0.47, SP
0.352, PIR
0.378; SM:
SP0.668,
PIR0.337; LFQ
0.576, LFX 41Hz
- Tonality (Preference) Score is 6.33
with an EQ and would be 8.13 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.409,
LW 0.29, SP
0.275, PIR
0.219; SM:
SP0.919,
PIR0.918; LFQ 0.576, LFX 38Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.8dB.
|
| Type |
Freq |
Q |
Gain |
| 5 |
378.0 |
1.06 |
2.25 |
| 3 |
447.0 |
1.44 |
-1.6 |
| 3 |
584.0 |
2.43 |
2.29 |
| 3 |
903.0 |
2.15 |
-2.84 |
| 3 |
1491.0 |
1.44 |
2.33 |
| 3 |
2014.0 |
2.37 |
2.05 |
| 3 |
4064.0 |
1.05 |
-1.57 |
| 3 |
9064.0 |
2.18 |
1.47 |
| 3 |
12246.0 |
0.92 |
-1.55 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
maiky76@ASR (IIR)
|
|
Set preamp gain to: -2.1dB.
|
| Type |
Freq |
Q |
Gain |
| 1 |
43.0 |
1.14 |
0.0 |
| 3 |
380.5 |
2.43 |
-1.57 |
| 3 |
896.5 |
1.88 |
-4.13 |
| 3 |
1712.0 |
1.41 |
1.82 |
| 3 |
3942.0 |
1.05 |
-3.04 |
| 3 |
12184.0 |
2.73 |
-3.6 |
|
Download
|
These EQ is designed by ASR member maiky76. These EQ optimise the Harman score and is a good start for far field listening like in your living room.
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -1.8dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
317.0 |
10.0 |
0.6 |
| 3 |
362.0 |
6.0 |
-1.1 |
| 3 |
599.0 |
8.0 |
1.1 |
| 3 |
704.0 |
15.0 |
-0.5 |
| 3 |
902.0 |
2.3 |
-3.6 |
| 3 |
1220.0 |
7.0 |
1.3 |
| 3 |
1562.0 |
10.0 |
2.2 |
| 3 |
1697.0 |
15.0 |
-0.6 |
| 3 |
1917.0 |
14.0 |
1.1 |
| 3 |
2280.0 |
11.0 |
1.8 |
| 3 |
2485.0 |
12.0 |
-1.3 |
| 3 |
2760.0 |
13.0 |
1.1 |
| 3 |
3005.0 |
5.5 |
-1.6 |
| 3 |
3700.0 |
8.0 |
-2.5 |
| 3 |
4295.0 |
10.0 |
-1.2 |
| 3 |
4855.0 |
13.0 |
-1.3 |
| 3 |
5380.0 |
10.0 |
-1.4 |
| 3 |
6850.0 |
6.0 |
-0.9 |
| 3 |
9100.0 |
2.5 |
1.2 |
| 3 |
12150.0 |
1.7 |
-3.4 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.5 |
| 3 |
40.0 |
2.14 |
0.5 |
| 3 |
63.0 |
2.14 |
0.5 |
| 3 |
100.0 |
2.14 |
0.5 |
| 3 |
160.0 |
2.14 |
0.25 |
| 3 |
250.0 |
2.14 |
0.25 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
-0.25 |
| 3 |
1600.0 |
2.14 |
0.25 |
| 3 |
2500.0 |
2.14 |
0.0 |
| 3 |
4000.0 |
2.14 |
-0.5 |
| 3 |
6300.0 |
2.14 |
-0.5 |
| 3 |
10000.0 |
2.14 |
-0.5 |
| 3 |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.25 |
| 3 |
31.0 |
4.32 |
0.25 |
| 3 |
40.0 |
4.32 |
0.25 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
0.25 |
| 3 |
100.0 |
4.32 |
0.25 |
| 3 |
125.0 |
4.32 |
0.25 |
| 3 |
160.0 |
4.32 |
0.25 |
| 3 |
200.0 |
4.32 |
0.25 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
-0.25 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
0.0 |
| 3 |
1600.0 |
4.32 |
0.25 |
| 3 |
2000.0 |
4.32 |
0.25 |
| 3 |
2500.0 |
4.32 |
0.0 |
| 3 |
3150.0 |
4.32 |
-0.25 |
| 3 |
4000.0 |
4.32 |
-0.5 |
| 3 |
5000.0 |
4.32 |
-0.5 |
| 3 |
6300.0 |
4.32 |
-0.25 |
| 3 |
8000.0 |
4.32 |
-0.25 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
-0.5 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
