What we know about the measurement:
Quality of the measurement data is
high .
Origin of the data is ASR.
Format of the data is
generated by a Klippel NFS
.
Sensitivity: 81.0 dB (avg. 100Hz-1kHz for 2.83V measured at 1m ).
-3dB (resp. -6db) point v.s. reference is at 124.5Hz (resp. 74.7Hz).
Reference level is normalised to 0.9dB
computed over the frequency range [300.0Hz,
5000.0Hz].
Frequency deviation is 7.6dB over the same frequency range.
Directivity
Horizontal directivity
is (-40.0°, 40.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Vertical directivity
is (-40.0°, 30.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Tonality (Preference) Score
Tonality (Preference) Score is 1.21
and would be 4.28 with a
perfect subwoofer.
Details:
NBD: ON 1.018,
LW 0.543, SP
0.37, PIR
0.393; SM:
SP0.703,
PIR0.136; LFQ
0.963, LFX 74Hz
Tonality (Preference) Score is 4.6
with an EQ and would be 6.97 with a
perfect subwoofer and the same EQ.
Details:
NBD: ON 0.795,
LW 0.372, SP
0.352, PIR
0.301; SM:
SP0.916,
PIR0.934; LFQ 0.822, LFX 51Hz
Link to original Review: eac review .
.
AutomaticEQ (IIR)
Set preamp gain to: -4.0dB .
Type
Freq
Q
Gain
PK
60.0
0.9
2.98
PK
130.0
0.25
1.2
PK
765.0
1.5
-1.8
PK
1121.0
2.98
2.38
PK
2964.0
2.99
-0.96
PK
4495.0
3.0
-3.77
PK
9989.0
0.78
-3.41
Download
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
maiky76@ASR LW (IIR)
Set preamp gain to: -1.5dB .
Type
Freq
Q
Gain
HP
72.01
1.04
0.0
PK
724.61
1.91
-2.33
PK
1137.24
3.9
1.92
PK
3811.42
1.19
-2.58
PK
4300.09
6.96
-3.35
PK
11691.68
1.11
-1.83
Download
These EQ is designed by ASR member maiky76. These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
Graphic EQ 15 bands
Set preamp gain to: -0.4dB .
Type
Freq
Q
Gain
PK
25.0
2.14
0.25
PK
40.0
2.14
0.25
PK
63.0
2.14
0.25
PK
100.0
2.14
0.25
PK
160.0
2.14
0.25
PK
250.0
2.14
0.0
PK
400.0
2.14
0.0
PK
630.0
2.14
-0.25
PK
1000.0
2.14
0.0
PK
1600.0
2.14
0.0
PK
2500.0
2.14
-0.25
PK
4000.0
2.14
-0.75
PK
6300.0
2.14
-0.5
PK
10000.0
2.14
-0.5
PK
16000.0
2.14
-0.5
Download
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
Set preamp gain to: -0.8dB .
Type
Freq
Q
Gain
PK
20.0
4.32
0.0
PK
25.0
4.32
0.5
PK
31.0
4.32
0.5
PK
40.0
4.32
0.5
PK
50.0
4.32
0.5
PK
63.0
4.32
0.5
PK
80.0
4.32
0.5
PK
100.0
4.32
0.5
PK
125.0
4.32
0.5
PK
160.0
4.32
0.25
PK
200.0
4.32
0.25
PK
250.0
4.32
0.25
PK
315.0
4.32
0.25
PK
400.0
4.32
0.0
PK
500.0
4.32
0.0
PK
630.0
4.32
-0.25
PK
800.0
4.32
-0.25
PK
1000.0
4.32
0.0
PK
1250.0
4.32
0.25
PK
1600.0
4.32
0.0
PK
2000.0
4.32
-0.25
PK
2500.0
4.32
0.0
PK
3150.0
4.32
-0.25
PK
4000.0
4.32
-0.5
PK
5000.0
4.32
-0.5
PK
6300.0
4.32
-0.5
PK
8000.0
4.32
-0.5
PK
10000.0
4.32
-0.5
PK
12000.0
4.32
-0.75
PK
16000.0
4.32
-0.75
PK
20000.0
4.32
0.0
Download
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
