What we know about the measurement:
Quality of the measurement data is
low .
Origin of the data is Misc.
Format of the data is
a set of 36 horizontal and 36 vertical measurements
.
Sensitivity: 67.9 dB (avg. 100Hz-1kHz for 2.83V measured at 1m ).
-3dB (resp. -6db) point v.s. reference is at 52.6Hz (resp. 45.6Hz).
Reference level is normalised to -0.5dB
computed over the frequency range [300.0Hz,
5000.0Hz].
Frequency deviation is 10.7dB over the same frequency range.
Directivity
Horizontal directivity
is (-10.0°, 10.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Vertical directivity
is (-20.0°, 10.0° )
between 1kHz and 10kHz. Angle computed for +/-6dB.
Tonality (Preference) Score
Tonality (Preference) Score is 2.57
and would be 4.58 with a
perfect subwoofer.
Details:
NBD: ON 0.94,
LW 0.752, SP
0.709, PIR
0.711; SM:
SP0.759,
PIR0.588; LFQ
0.255, LFX 42Hz
Tonality (Preference) Score is 5.35
with an EQ and would be 6.69 with a
perfect subwoofer and the same EQ.
Details:
NBD: ON 0.656,
LW 0.473, SP
0.532, PIR
0.432; SM:
SP0.85,
PIR0.833; LFQ 0.386, LFX 29Hz
Link to original Review: asr review .
.
AutomaticEQ (IIR)
Set preamp gain to: -5.6dB .
Type
Freq
Q
Gain
PK
29.0
0.56
6.0
PK
80.0
1.82
-6.75
PK
190.0
2.99
-1.99
PK
522.0
0.69
-3.0
PK
1642.0
2.98
-3.2
PK
2670.0
1.0
6.0
PK
9648.0
0.5
-4.16
Download
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
AutomaticEQ LW (IIR)
Set preamp gain to: -2.9dB .
Type
Freq
Q
Gain
PK
52.0
2.93
3.0
PK
80.0
2.0
-5.06
PK
109.0
2.05
-1.12
PK
197.0
2.95
-2.26
PK
424.0
1.05
-2.5
PK
879.0
2.67
-3.24
PK
2579.0
1.0
3.0
Download
These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
AutomaticEQ Score (IIR)
Set preamp gain to: -5.6dB .
Type
Freq
Q
Gain
PK
29.0
0.56
6.0
PK
80.0
1.89
-6.75
PK
332.0
0.55
-2.5
PK
879.0
3.0
-2.82
PK
1642.0
2.99
-3.38
PK
2670.0
1.0
6.0
PK
9648.0
0.5
-4.09
Download
maiky76@ASR LW (IIR)
Set preamp gain to: -8.0dB .
Type
Freq
Q
Gain
HP
50.9
2.11
0.0
PK
77.8
1.77
-6.45
PK
876.9
4.2
-1.9
PK
1267.4
6.89
2.31
PK
1626.5
0.66
-0.95
PK
2621.1
1.38
8.66
PK
8296.1
6.01
-2.2
Download
These EQ is designed by ASR member maiky76. These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
maiky76@ASR (IIR)
Set preamp gain to: -7.9dB .
Type
Freq
Q
Gain
HP
50.9
2.11
0.0
PK
78.0
1.77
-6.45
PK
864.9
6.87
-1.9
PK
1282.2
5.84
4.92
PK
1631.6
1.42
-2.77
PK
2741.8
1.52
8.66
PK
8156.9
5.26
-2.2
Download
These EQ is designed by ASR member maiky76. These EQ optimise the Harman score and is a good start for far field listening like in your living room.
Comparison betweens various EQs
Improvements made by EQ
