What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ErinsAudioCorner.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 60.1Hz (resp. 54.2Hz).
-
Reference level is normalised to -0.6dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.5dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-10.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.98
and would be 7.35 with a
perfect subwoofer.
- Details:
NBD: ON 0.388,
LW 0.367, SP
0.35, PIR
0.338; SM:
SP0.862,
PIR0.71; LFQ
0.464, LFX 51Hz
- Tonality (Preference) Score is 6.13
with an EQ and would be 8.33 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.309,
LW 0.267, SP
0.306, PIR
0.262; SM:
SP0.973,
PIR0.949; LFQ 0.562, LFX 46Hz
-
Link to original Review: eac review.
Links to other reviews: asr review
.
AutomaticEQ (IIR)
|
Set preamp gain to: -3.2dB.
|
Type |
Freq |
Q |
Gain |
3 |
49.0 |
1.24 |
2.5 |
3 |
211.0 |
0.67 |
2.29 |
3 |
879.0 |
0.77 |
-1.42 |
3 |
3068.0 |
2.83 |
2.89 |
3 |
4194.0 |
2.98 |
2.01 |
3 |
9001.0 |
1.63 |
2.32 |
3 |
9989.0 |
2.48 |
-1.13 |
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
Graphic EQ 15 bands
|
Set preamp gain to: -0.6dB.
|
Type |
Freq |
Q |
Gain |
3 |
25.0 |
2.14 |
0.25 |
3 |
40.0 |
2.14 |
0.25 |
3 |
63.0 |
2.14 |
0.25 |
3 |
100.0 |
2.14 |
0.25 |
3 |
160.0 |
2.14 |
0.25 |
3 |
250.0 |
2.14 |
0.25 |
3 |
400.0 |
2.14 |
0.0 |
3 |
630.0 |
2.14 |
-0.25 |
3 |
1000.0 |
2.14 |
0.0 |
3 |
1600.0 |
2.14 |
0.0 |
3 |
2500.0 |
2.14 |
0.25 |
3 |
4000.0 |
2.14 |
0.5 |
3 |
6300.0 |
2.14 |
0.25 |
3 |
10000.0 |
2.14 |
0.25 |
3 |
16000.0 |
2.14 |
0.5 |
Download
|
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
|
Set preamp gain to: -0.7dB.
|
Type |
Freq |
Q |
Gain |
3 |
20.0 |
4.32 |
0.0 |
3 |
25.0 |
4.32 |
0.25 |
3 |
31.0 |
4.32 |
0.25 |
3 |
40.0 |
4.32 |
0.25 |
3 |
50.0 |
4.32 |
0.25 |
3 |
63.0 |
4.32 |
0.25 |
3 |
80.0 |
4.32 |
0.25 |
3 |
100.0 |
4.32 |
0.25 |
3 |
125.0 |
4.32 |
0.25 |
3 |
160.0 |
4.32 |
0.25 |
3 |
200.0 |
4.32 |
0.25 |
3 |
250.0 |
4.32 |
0.25 |
3 |
315.0 |
4.32 |
0.25 |
3 |
400.0 |
4.32 |
0.0 |
3 |
500.0 |
4.32 |
0.0 |
3 |
630.0 |
4.32 |
-0.25 |
3 |
800.0 |
4.32 |
-0.25 |
3 |
1000.0 |
4.32 |
0.0 |
3 |
1250.0 |
4.32 |
-0.25 |
3 |
1600.0 |
4.32 |
0.0 |
3 |
2000.0 |
4.32 |
0.0 |
3 |
2500.0 |
4.32 |
0.25 |
3 |
3150.0 |
4.32 |
0.5 |
3 |
4000.0 |
4.32 |
0.5 |
3 |
5000.0 |
4.32 |
0.25 |
3 |
6300.0 |
4.32 |
0.25 |
3 |
8000.0 |
4.32 |
0.25 |
3 |
10000.0 |
4.32 |
0.25 |
3 |
12000.0 |
4.32 |
0.25 |
3 |
16000.0 |
4.32 |
0.5 |
3 |
20000.0 |
4.32 |
0.0 |
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
