What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 83.4dB (avg. 100Hz-1kHz for 2.83V estimated at 1m)
-
-3dB (resp. -6db) point v.s. reference is at 60.1Hz (resp. 52.7Hz).
-
Reference level is normalised to -0.5dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 5.6dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-70.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 3.47
and would be 5.89 with a
perfect subwoofer.
- Details:
NBD: ON 0.656,
LW 0.563, SP
0.515, PIR
0.518; SM:
SP0.778,
PIR0.601; LFQ
0.666, LFX 52Hz
- Tonality (Preference) Score is 5.76
with an EQ and would be 7.9 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.412,
LW 0.322, SP
0.356, PIR
0.313; SM:
SP0.953,
PIR0.939; LFQ 0.589, LFX 45Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.6dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
44.0 |
0.25 |
2.99 |
| 3 |
105.0 |
1.29 |
-5.54 |
| 3 |
849.0 |
2.99 |
-3.57 |
| 3 |
3177.0 |
1.57 |
3.0 |
| 3 |
4342.0 |
2.89 |
-2.44 |
| 3 |
9989.0 |
0.71 |
-3.78 |
| 3 |
12736.0 |
2.82 |
1.56 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -3.6dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
347.0 |
10.0 |
0.4 |
| 3 |
409.0 |
11.0 |
0.9 |
| 3 |
465.0 |
4.5 |
-0.8 |
| 3 |
875.0 |
2.5 |
-3.9 |
| 3 |
958.0 |
10.0 |
-1.1 |
| 3 |
1075.0 |
5.5 |
3.7 |
| 3 |
1435.0 |
12.0 |
0.3 |
| 3 |
1565.0 |
13.0 |
-0.5 |
| 3 |
1692.0 |
7.0 |
1.0 |
| 3 |
1945.0 |
10.0 |
1.9 |
| 3 |
2238.0 |
18.0 |
1.0 |
| 3 |
2820.0 |
10.0 |
-1.3 |
| 3 |
3040.0 |
20.0 |
1.0 |
| 3 |
3220.0 |
2.5 |
3.7 |
| 3 |
4490.0 |
2.7 |
-1.8 |
| 3 |
6380.0 |
2.9 |
-1.5 |
| 3 |
8580.0 |
3.1 |
-2.2 |
| 3 |
10720.0 |
3.2 |
-1.9 |
| 3 |
13400.0 |
4.0 |
0.5 |
| 3 |
15750.0 |
4.5 |
-0.4 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.3dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.25 |
| 3 |
40.0 |
2.14 |
0.25 |
| 3 |
63.0 |
2.14 |
0.25 |
| 3 |
100.0 |
2.14 |
-0.5 |
| 3 |
160.0 |
2.14 |
-0.25 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.0 |
| 3 |
630.0 |
2.14 |
0.0 |
| 3 |
1000.0 |
2.14 |
0.0 |
| 3 |
1600.0 |
2.14 |
0.0 |
| 3 |
2500.0 |
2.14 |
0.25 |
| 3 |
4000.0 |
2.14 |
0.0 |
| 3 |
6300.0 |
2.14 |
-0.25 |
| 3 |
10000.0 |
2.14 |
-0.25 |
| 3 |
16000.0 |
2.14 |
0.0 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.5 |
| 3 |
31.0 |
4.32 |
0.5 |
| 3 |
40.0 |
4.32 |
0.5 |
| 3 |
50.0 |
4.32 |
0.5 |
| 3 |
63.0 |
4.32 |
0.25 |
| 3 |
80.0 |
4.32 |
-0.25 |
| 3 |
100.0 |
4.32 |
-0.5 |
| 3 |
125.0 |
4.32 |
-0.5 |
| 3 |
160.0 |
4.32 |
-0.25 |
| 3 |
200.0 |
4.32 |
0.0 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.0 |
| 3 |
500.0 |
4.32 |
0.0 |
| 3 |
630.0 |
4.32 |
0.0 |
| 3 |
800.0 |
4.32 |
-0.5 |
| 3 |
1000.0 |
4.32 |
-0.25 |
| 3 |
1250.0 |
4.32 |
0.25 |
| 3 |
1600.0 |
4.32 |
0.0 |
| 3 |
2000.0 |
4.32 |
0.25 |
| 3 |
2500.0 |
4.32 |
0.25 |
| 3 |
3150.0 |
4.32 |
0.5 |
| 3 |
4000.0 |
4.32 |
0.25 |
| 3 |
5000.0 |
4.32 |
-0.25 |
| 3 |
6300.0 |
4.32 |
-0.25 |
| 3 |
8000.0 |
4.32 |
-0.25 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
0.0 |
| 3 |
16000.0 |
4.32 |
0.0 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
