What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is Meyer Sound.
-
Format of the data is
a GLL file
.
-
-3dB (resp. -6db) point v.s. reference is at 51.5Hz (resp. 48.7Hz).
-
Reference level is normalised to -4.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 12.2dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-40.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for toursound speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is 0.87
and would be 3.14 with a
perfect subwoofer.
- Details:
NBD: ON 1.458,
LW 0.801, SP
0.812, PIR
0.68; SM:
SP0.544,
PIR0.485; LFQ
2.933, LFX 48Hz
- Tonality (Preference) Score is 2.49
with an EQ and would be 4.81 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 1.24,
LW 0.629, SP
0.669, PIR
0.495; SM:
SP0.788,
PIR0.732; LFQ 2.933, LFX 49Hz
-
Note: Data provided by Meyer is high quality above 50Hz-100Hz.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -5.2dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
51.0 |
1.3 |
2.4 |
| 3 |
109.0 |
0.54 |
-2.29 |
| 3 |
478.0 |
2.97 |
2.3 |
| 3 |
691.0 |
3.0 |
1.47 |
| 3 |
998.0 |
3.0 |
1.68 |
| 3 |
2380.0 |
0.76 |
2.93 |
| 3 |
2813.0 |
2.95 |
2.57 |
| 3 |
6069.0 |
3.0 |
-3.0 |
| 3 |
11077.0 |
1.3 |
-3.0 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
25.0 |
2.14 |
0.25 |
| 3 |
40.0 |
2.14 |
0.25 |
| 3 |
63.0 |
2.14 |
-0.25 |
| 3 |
100.0 |
2.14 |
0.0 |
| 3 |
160.0 |
2.14 |
0.0 |
| 3 |
250.0 |
2.14 |
0.0 |
| 3 |
400.0 |
2.14 |
0.25 |
| 3 |
630.0 |
2.14 |
0.5 |
| 3 |
1000.0 |
2.14 |
0.5 |
| 3 |
1600.0 |
2.14 |
0.5 |
| 3 |
2500.0 |
2.14 |
0.75 |
| 3 |
4000.0 |
2.14 |
0.5 |
| 3 |
6300.0 |
2.14 |
0.25 |
| 3 |
10000.0 |
2.14 |
-0.25 |
| 3 |
16000.0 |
2.14 |
0.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.0dB.
|
| Type |
Freq |
Q |
Gain |
| 3 |
20.0 |
4.32 |
0.0 |
| 3 |
25.0 |
4.32 |
0.25 |
| 3 |
31.0 |
4.32 |
0.25 |
| 3 |
40.0 |
4.32 |
0.25 |
| 3 |
50.0 |
4.32 |
0.25 |
| 3 |
63.0 |
4.32 |
-0.25 |
| 3 |
80.0 |
4.32 |
-0.25 |
| 3 |
100.0 |
4.32 |
0.0 |
| 3 |
125.0 |
4.32 |
0.0 |
| 3 |
160.0 |
4.32 |
0.0 |
| 3 |
200.0 |
4.32 |
-0.25 |
| 3 |
250.0 |
4.32 |
0.0 |
| 3 |
315.0 |
4.32 |
0.0 |
| 3 |
400.0 |
4.32 |
0.25 |
| 3 |
500.0 |
4.32 |
0.25 |
| 3 |
630.0 |
4.32 |
0.5 |
| 3 |
800.0 |
4.32 |
0.25 |
| 3 |
1000.0 |
4.32 |
0.5 |
| 3 |
1250.0 |
4.32 |
0.5 |
| 3 |
1600.0 |
4.32 |
0.5 |
| 3 |
2000.0 |
4.32 |
0.75 |
| 3 |
2500.0 |
4.32 |
0.5 |
| 3 |
3150.0 |
4.32 |
0.5 |
| 3 |
4000.0 |
4.32 |
0.25 |
| 3 |
5000.0 |
4.32 |
0.25 |
| 3 |
6300.0 |
4.32 |
0.25 |
| 3 |
8000.0 |
4.32 |
0.5 |
| 3 |
10000.0 |
4.32 |
-0.25 |
| 3 |
12000.0 |
4.32 |
-0.25 |
| 3 |
16000.0 |
4.32 |
0.25 |
| 3 |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
