What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ErinsAudioCorner.
-
Format of the data is
generated by a Klippel NFS
.
-
-3dB (resp. -6db) point v.s. reference is at 43.9Hz (resp. 39.6Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.7dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 60.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.0
and would be 5.88 with a
perfect subwoofer.
- Details:
NBD: ON 0.735,
LW 0.492, SP
0.404, PIR
0.411; SM:
SP0.856,
PIR0.544; LFQ
1.11, LFX 39Hz
- Tonality (Preference) Score is 5.53
with an EQ and would be 7.26 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.625,
LW 0.395, SP
0.304, PIR
0.289; SM:
SP0.944,
PIR0.864; LFQ 1.11, LFX 36Hz
-
Link to original Review: eac review.
Links to other reviews: asr review
, yt review
.
-
Vendor specifications:
- Size
- Width 285mm
- Height 441mm
- Depth 254mm
- Weight 10.4kg
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.7dB.
|
| Type |
Freq |
Q |
Gain |
| LS |
43.0 |
0.98 |
2.84 |
| PK |
164.0 |
2.74 |
1.87 |
| PK |
354.0 |
2.99 |
1.77 |
| PK |
1884.0 |
2.46 |
1.88 |
| PK |
2302.0 |
2.87 |
-2.05 |
| PK |
3676.0 |
1.2 |
2.19 |
| PK |
4345.0 |
2.97 |
-2.16 |
| PK |
10361.0 |
2.49 |
1.12 |
| PK |
14965.0 |
1.12 |
-2.8 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -1.5dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
318.0 |
15.0 |
0.7 |
| PK |
348.0 |
10.0 |
0.8 |
| PK |
421.0 |
11.0 |
-0.9 |
| PK |
504.0 |
4.5 |
-0.8 |
| PK |
631.0 |
3.2 |
-1.0 |
| PK |
900.0 |
4.2 |
-0.8 |
| PK |
1240.0 |
4.3 |
-1.9 |
| PK |
1950.0 |
11.0 |
1.1 |
| PK |
2390.0 |
10.0 |
-1.7 |
| PK |
2630.0 |
10.0 |
-0.8 |
| PK |
3380.0 |
7.0 |
0.7 |
| PK |
4650.0 |
10.0 |
-0.5 |
| PK |
5200.0 |
9.0 |
2.1 |
| PK |
7100.0 |
2.2 |
-2.7 |
| PK |
7950.0 |
8.0 |
2.0 |
| PK |
8830.0 |
12.0 |
-0.8 |
| PK |
9800.0 |
6.0 |
2.4 |
| PK |
12250.0 |
7.0 |
1.6 |
| PK |
13600.0 |
2.3 |
-2.0 |
| PK |
15600.0 |
4.0 |
-1.6 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.6dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.0 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
0.25 |
| PK |
250.0 |
2.14 |
-0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
-0.25 |
| PK |
1000.0 |
2.14 |
-0.25 |
| PK |
1600.0 |
2.14 |
0.0 |
| PK |
2500.0 |
2.14 |
-0.25 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
-0.25 |
| PK |
16000.0 |
2.14 |
-0.5 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.0 |
| PK |
80.0 |
4.32 |
0.0 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.25 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
-0.25 |
| PK |
315.0 |
4.32 |
0.25 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
-0.25 |
| PK |
800.0 |
4.32 |
-0.25 |
| PK |
1000.0 |
4.32 |
-0.25 |
| PK |
1250.0 |
4.32 |
-0.25 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
-0.25 |
| PK |
2500.0 |
4.32 |
-0.25 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
0.0 |
| PK |
6300.0 |
4.32 |
-0.25 |
| PK |
8000.0 |
4.32 |
-0.5 |
| PK |
10000.0 |
4.32 |
-0.25 |
| PK |
12000.0 |
4.32 |
-0.5 |
| PK |
16000.0 |
4.32 |
-0.5 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
