We have multiple measurements for this speaker. Click here to see the default one (which is higher quality if we have one measurement better than the others).
- Quality of the measurement data is medium.
- Origin of the data is KEF.
- Format of the data is .
- -3dB (resp. -6db) point v.s. reference is at 62.9Hz (resp. 42.9Hz).
- Reference level is normalised to 0.3dB computed over the frequency range [300.0Hz, 5000.0Hz].
- Frequency deviation is 3.3dB over the same frequency range.
- Tonality (Preference) Score
- Tonality (Preference) Score is 5.61
and would be 7.58 with a
perfect subwoofer.
- Details: NBD: ON 0.475, LW 0.406, SP 0.361, PIR 0.351; SM: SP0.967, PIR0.919; LFQ 0.748, LFX 41Hz
- Tonality (Preference) Score is 6.11
with an EQ and would be 7.89 with a
perfect subwoofer and the same EQ.
- Details: NBD: ON 0.413, LW 0.35, SP 0.317, PIR 0.296; SM: SP0.963, PIR0.915; LFQ 0.748, LFX 37Hz
- Tonality (Preference) Score is 5.61
and would be 7.58 with a
perfect subwoofer.
- Note: the off-axis average curves are truncated at 200Hz as this is close to the LF cut-off limit of our anechoic chamber. The on-axis LF response has been compensated using ground plane measurements carried out in free-field and is therefore valid only for that singular curve..
