What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is ASR.
-
Format of the data is
generated by a Klippel NFS
.
-
Sensitivity: 87.2dB (avg. 100Hz-1kHz for 2.83V measured at 1m).
-
-3dB (resp. -6db) point v.s. reference is at 71.8Hz (resp. 42.5Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.7dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-50.0°, 50.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-40.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 4.79
and would be 6.67 with a
perfect subwoofer.
- Details:
NBD: ON 0.417,
LW 0.334, SP
0.301, PIR
0.268; SM:
SP0.642,
PIR0.359; LFQ
0.896, LFX 39Hz
- Tonality (Preference) Score is 6.44
with an EQ and would be 8.17 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.403,
LW 0.296, SP
0.252, PIR
0.225; SM:
SP0.934,
PIR0.936; LFQ 0.896, LFX 36Hz
- Link to Original review.
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
41.0 |
0.79 |
2.98 |
| PK |
1642.0 |
2.95 |
1.93 |
| PK |
2094.0 |
2.97 |
2.71 |
| PK |
3779.0 |
0.41 |
-1.6 |
| PK |
4051.0 |
2.98 |
1.89 |
| PK |
4495.0 |
2.8 |
-1.41 |
| PK |
13652.0 |
0.25 |
-2.06 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
flipflop@ASR (IIR)
|
|
Set preamp gain to: -3.8dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
327.0 |
15.0 |
0.9 |
| PK |
404.0 |
12.0 |
1.6 |
| PK |
557.0 |
3.0 |
0.9 |
| PK |
854.0 |
7.0 |
0.6 |
| PK |
1028.0 |
15.0 |
0.8 |
| PK |
1188.0 |
13.0 |
0.7 |
| PK |
1361.0 |
7.0 |
-0.7 |
| PK |
1565.0 |
6.0 |
2.6 |
| PK |
1880.0 |
5.5 |
2.0 |
| PK |
2080.0 |
19.0 |
2.0 |
| PK |
2270.0 |
7.8 |
2.6 |
| PK |
2505.0 |
16.0 |
-1.8 |
| PK |
2725.0 |
12.0 |
1.2 |
| PK |
3340.0 |
9.0 |
0.9 |
| PK |
3970.0 |
13.0 |
1.2 |
| PK |
5026.0 |
4.5 |
-1.1 |
| PK |
8867.0 |
0.6 |
-1.3 |
| PK |
10700.0 |
4.0 |
-0.6 |
| PK |
14080.0 |
2.3 |
0.6 |
| HS |
16800.0 |
1.5772935127949521 |
-2.9 |
|
Download
|
These EQ is designed by ASR member flipflop.
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.5 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
0.0 |
| PK |
250.0 |
2.14 |
-0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.0 |
| PK |
1600.0 |
2.14 |
0.25 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
-0.5 |
| PK |
6300.0 |
2.14 |
-0.75 |
| PK |
10000.0 |
2.14 |
-0.75 |
| PK |
16000.0 |
2.14 |
-0.75 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.25 |
| PK |
31.0 |
4.32 |
0.25 |
| PK |
40.0 |
4.32 |
0.25 |
| PK |
50.0 |
4.32 |
0.25 |
| PK |
63.0 |
4.32 |
0.25 |
| PK |
80.0 |
4.32 |
0.25 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
-0.25 |
| PK |
315.0 |
4.32 |
-0.25 |
| PK |
400.0 |
4.32 |
0.0 |
| PK |
500.0 |
4.32 |
0.0 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.0 |
| PK |
1000.0 |
4.32 |
0.0 |
| PK |
1250.0 |
4.32 |
-0.25 |
| PK |
1600.0 |
4.32 |
0.0 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
-0.25 |
| PK |
3150.0 |
4.32 |
-0.5 |
| PK |
4000.0 |
4.32 |
-0.5 |
| PK |
5000.0 |
4.32 |
-0.5 |
| PK |
6300.0 |
4.32 |
-0.75 |
| PK |
8000.0 |
4.32 |
-0.75 |
| PK |
10000.0 |
4.32 |
-0.75 |
| PK |
12000.0 |
4.32 |
-0.75 |
| PK |
16000.0 |
4.32 |
-0.75 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
