What we know about the measurement:
- Quality of the measurement data is
high.
-
Origin of the data is HK Audio.
-
Format of the data is
a GLL file
.
-
-3dB (resp. -6db) point v.s. reference is at 73.0Hz (resp. 65.0Hz).
-
Reference level is normalised to 0.4dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 5.4dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 1.53
and would be 4.5 with a
perfect subwoofer.
- Details:
NBD: ON 0.608,
LW 0.586, SP
0.67, PIR
0.622; SM:
SP0.408,
PIR0.085; LFQ
1.694, LFX 70Hz
- Tonality (Preference) Score is 4.2
with an EQ and would be 7.01 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.482,
LW 0.415, SP
0.544, PIR
0.471; SM:
SP0.907,
PIR0.834; LFQ 1.697, LFX 64Hz
-
Link to original Review: sos review.
.
-
Vendor specifications:
- Dispersion: 60° horizontal and 55° vertical.
- SPL
- continuous: 127 dB
- peak: 135 dB
- Size
- Width 365mm
- Height 668mm
- Depth 370mm
- Weight 23.9kg
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -3.0dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
62.0 |
2.09 |
2.99 |
| PK |
98.0 |
1.61 |
-1.79 |
| PK |
487.0 |
0.4 |
1.24 |
| PK |
504.0 |
1.69 |
-3.28 |
| PK |
1381.0 |
2.15 |
2.99 |
| PK |
2324.0 |
2.46 |
-2.28 |
| PK |
12736.0 |
0.56 |
-7.52 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
AutomaticEQ LW (IIR)
|
|
Set preamp gain to: -4.1dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
73.0 |
2.57 |
2.86 |
| PK |
96.0 |
2.51 |
-1.78 |
| PK |
529.0 |
2.82 |
-2.99 |
| PK |
965.0 |
0.55 |
1.52 |
| PK |
1348.0 |
2.63 |
2.91 |
| PK |
13997.0 |
0.39 |
-2.87 |
| PK |
13997.0 |
2.3 |
-2.54 |
|
Download
|
These EQ optimise for a flat listening window and is a good start for near field listening like on your desk.
|
AutomaticEQ Score (IIR)
|
|
Set preamp gain to: -4.4dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
73.0 |
2.39 |
2.99 |
| PK |
96.0 |
2.25 |
-1.94 |
| PK |
529.0 |
2.82 |
-2.01 |
| PK |
1141.0 |
1.36 |
2.34 |
| PK |
1442.0 |
2.91 |
2.95 |
| PK |
13537.0 |
0.36 |
-2.97 |
| PK |
14473.0 |
0.79 |
-2.92 |
|
Download
|
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -0.7dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.5 |
| PK |
40.0 |
2.14 |
0.5 |
| PK |
63.0 |
2.14 |
0.5 |
| PK |
100.0 |
2.14 |
-0.25 |
| PK |
160.0 |
2.14 |
-0.25 |
| PK |
250.0 |
2.14 |
0.25 |
| PK |
400.0 |
2.14 |
0.0 |
| PK |
630.0 |
2.14 |
0.0 |
| PK |
1000.0 |
2.14 |
0.5 |
| PK |
1600.0 |
2.14 |
0.5 |
| PK |
2500.0 |
2.14 |
0.0 |
| PK |
4000.0 |
2.14 |
-0.25 |
| PK |
6300.0 |
2.14 |
-0.5 |
| PK |
10000.0 |
2.14 |
-0.75 |
| PK |
16000.0 |
2.14 |
-0.75 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -0.9dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.5 |
| PK |
31.0 |
4.32 |
0.5 |
| PK |
40.0 |
4.32 |
0.5 |
| PK |
50.0 |
4.32 |
0.5 |
| PK |
63.0 |
4.32 |
0.5 |
| PK |
80.0 |
4.32 |
0.25 |
| PK |
100.0 |
4.32 |
-0.25 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
-0.25 |
| PK |
200.0 |
4.32 |
0.25 |
| PK |
250.0 |
4.32 |
0.25 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
-0.25 |
| PK |
500.0 |
4.32 |
-0.25 |
| PK |
630.0 |
4.32 |
0.0 |
| PK |
800.0 |
4.32 |
0.25 |
| PK |
1000.0 |
4.32 |
0.5 |
| PK |
1250.0 |
4.32 |
0.75 |
| PK |
1600.0 |
4.32 |
0.5 |
| PK |
2000.0 |
4.32 |
0.0 |
| PK |
2500.0 |
4.32 |
0.0 |
| PK |
3150.0 |
4.32 |
0.0 |
| PK |
4000.0 |
4.32 |
-0.25 |
| PK |
5000.0 |
4.32 |
-0.5 |
| PK |
6300.0 |
4.32 |
-0.5 |
| PK |
8000.0 |
4.32 |
-0.5 |
| PK |
10000.0 |
4.32 |
-0.75 |
| PK |
12000.0 |
4.32 |
-1.0 |
| PK |
16000.0 |
4.32 |
-0.75 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
