Sensitivity: 132.1dB (avg. 100Hz-1kHz for 2.83V estimated at 1m)
. Sensitivity computed at the measurement distance (10m) over the same frequency range: 112.1dB.
-3dB (resp. -6db) point v.s. reference is at 67.0Hz (resp. 60.0Hz).
Reference level is normalised to -0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
Frequency deviation is 2.0dB over the same frequency range.
Directivity
Horizontal directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
Tonality (Preference) Score
Note: The tonality (Preference) score
does not make sense for toursound speakers. Don't give too much credits
to the value.
Tonality (Preference) Score is 4.39
and would be 7.05 with a
perfect subwoofer.
Details:
NBD: ON 0.38,
LW 0.321, SP
0.418, PIR
0.363; SM:
SP0.664,
PIR0.604; LFQ
3.392, LFX 60Hz
Tonality (Preference) Score is 5.54
with an EQ and would be 8.13 with a
perfect subwoofer and the same EQ.
Details:
NBD: ON 0.292,
LW 0.242, SP
0.378, PIR
0.289; SM:
SP0.886,
PIR0.882; LFQ 3.392, LFX 58Hz
Note: Relatively high smoothing; Pattern is 60x45.
