Sensitivity: 125.4dB (avg. 100Hz-1kHz for 2.83V estimated at 1m)
. Sensitivity computed at the measurement distance (10m) over the same frequency range: 105.4dB.
-3dB (resp. -6db) point v.s. reference is at 85.0Hz (resp. 73.0Hz).
Reference level is normalised to -0.2dB
computed over the frequency range [300.0Hz,
5000.0Hz].
Frequency deviation is 3.1dB over the same frequency range.
Directivity
Horizontal directivity
is (-40.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
Vertical directivity
is (-40.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
Tonality (Preference) Score
Note: The tonality (Preference) score
does not make sense for toursound speakers. Don't give too much credits
to the value.
Tonality (Preference) Score is 2.6
and would be 5.97 with a
perfect subwoofer.
Details:
NBD: ON 0.724,
LW 0.537, SP
0.561, PIR
0.532; SM:
SP0.786,
PIR0.726; LFQ
3.672, LFX 87Hz
Tonality (Preference) Score is 4.37
with an EQ and would be 7.56 with a
perfect subwoofer and the same EQ.
Details:
NBD: ON 0.44,
LW 0.35, SP
0.435, PIR
0.365; SM:
SP0.915,
PIR0.894; LFQ 3.672, LFX 79Hz
Note: Relatively high smoothing; Pattern is 100x100.
