What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is FBT.
-
Format of the data is
a GLL file
.
-
-3dB (resp. -6db) point v.s. reference is at 103.0Hz (resp. 71.0Hz).
-
Reference level is normalised to 0.0dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 2.7dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-40.0°, 40.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Tonality (Preference) Score is 2.36
and would be 5.56 with a
perfect subwoofer.
- Details:
NBD: ON 0.622,
LW 0.558, SP
0.527, PIR
0.535; SM:
SP0.705,
PIR0.443; LFQ
3.205, LFX 79Hz
- Tonality (Preference) Score is 4.98
with an EQ and would be 7.29 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.497,
LW 0.412, SP
0.395, PIR
0.382; SM:
SP0.928,
PIR0.859; LFQ 2.782, LFX 49Hz
AutomaticEQ (IIR)
|
Set preamp gain to: -5.1dB.
|
Type |
Freq |
Q |
Gain |
5 |
103.0 |
1.09 |
2.97 |
3 |
103.0 |
0.26 |
2.89 |
3 |
164.0 |
1.26 |
-2.94 |
3 |
262.0 |
2.57 |
1.78 |
3 |
366.0 |
1.94 |
-2.49 |
3 |
1442.0 |
2.85 |
1.64 |
3 |
1948.0 |
0.33 |
0.72 |
3 |
2461.0 |
2.95 |
1.89 |
3 |
15474.0 |
0.93 |
-2.56 |
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
Graphic EQ 15 bands
|
Set preamp gain to: -1.1dB.
|
Type |
Freq |
Q |
Gain |
3 |
25.0 |
2.14 |
0.75 |
3 |
40.0 |
2.14 |
0.75 |
3 |
63.0 |
2.14 |
0.75 |
3 |
100.0 |
2.14 |
0.75 |
3 |
160.0 |
2.14 |
0.0 |
3 |
250.0 |
2.14 |
0.5 |
3 |
400.0 |
2.14 |
-0.25 |
3 |
630.0 |
2.14 |
0.25 |
3 |
1000.0 |
2.14 |
0.0 |
3 |
1600.0 |
2.14 |
0.5 |
3 |
2500.0 |
2.14 |
0.75 |
3 |
4000.0 |
2.14 |
0.5 |
3 |
6300.0 |
2.14 |
0.0 |
3 |
10000.0 |
2.14 |
-0.5 |
3 |
16000.0 |
2.14 |
-1.25 |
Download
|
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
|
Set preamp gain to: -0.8dB.
|
Type |
Freq |
Q |
Gain |
3 |
20.0 |
4.32 |
0.0 |
3 |
25.0 |
4.32 |
0.5 |
3 |
31.0 |
4.32 |
0.5 |
3 |
40.0 |
4.32 |
0.5 |
3 |
50.0 |
4.32 |
0.5 |
3 |
63.0 |
4.32 |
0.5 |
3 |
80.0 |
4.32 |
0.5 |
3 |
100.0 |
4.32 |
0.5 |
3 |
125.0 |
4.32 |
0.25 |
3 |
160.0 |
4.32 |
0.0 |
3 |
200.0 |
4.32 |
0.0 |
3 |
250.0 |
4.32 |
0.25 |
3 |
315.0 |
4.32 |
0.0 |
3 |
400.0 |
4.32 |
-0.25 |
3 |
500.0 |
4.32 |
-0.25 |
3 |
630.0 |
4.32 |
0.0 |
3 |
800.0 |
4.32 |
0.0 |
3 |
1000.0 |
4.32 |
0.0 |
3 |
1250.0 |
4.32 |
0.25 |
3 |
1600.0 |
4.32 |
0.25 |
3 |
2000.0 |
4.32 |
0.0 |
3 |
2500.0 |
4.32 |
0.25 |
3 |
3150.0 |
4.32 |
-0.25 |
3 |
4000.0 |
4.32 |
0.0 |
3 |
5000.0 |
4.32 |
-0.25 |
3 |
6300.0 |
4.32 |
-0.25 |
3 |
8000.0 |
4.32 |
-0.25 |
3 |
10000.0 |
4.32 |
-0.5 |
3 |
12000.0 |
4.32 |
-0.25 |
3 |
16000.0 |
4.32 |
-1.0 |
3 |
20000.0 |
4.32 |
0.0 |
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
