What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is Danley.
-
Format of the data is
a GLL file
.
-
Sensitivity:
-
Sensitivity: 93.1dB (avg. 100Hz-1kHz for 2.83V estimated at 1m).
-
Sensitivity: 73.1dB computed at the measurement distance (10.0m) over the same frequency range.
-
-3dB (resp. -6db) point v.s. reference is at 22.4Hz (resp. 240.0Hz).
-
Reference level is normalised to 0.3dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 3.8dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-30.0°, 30.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for toursound speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is -6.46
and would be -0.75 with a
perfect subwoofer.
- Details:
NBD: ON 1.758,
LW 1.59, SP
1.431, PIR
1.499; SM:
SP0.074,
PIR0.184; LFQ
10.0, LFX 307Hz
- Tonality (Preference) Score is -3.14
with an EQ and would be 1.87 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 1.376,
LW 1.206, SP
1.098, PIR
1.128; SM:
SP0.205,
PIR0.429; LFQ 10.0, LFX 211Hz
AutomaticEQ (IIR)
|
Set preamp gain to: -8.8dB.
|
Type |
Freq |
Q |
Gain |
3 |
46.0 |
0.25 |
2.99 |
3 |
54.0 |
0.25 |
2.99 |
3 |
65.0 |
0.25 |
2.99 |
3 |
310.0 |
1.7 |
-7.89 |
3 |
714.0 |
0.88 |
-8.85 |
3 |
2023.0 |
3.0 |
-5.86 |
3 |
12736.0 |
1.52 |
2.99 |
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
Graphic EQ 15 bands
|
Set preamp gain to: -8.0dB.
|
Type |
Freq |
Q |
Gain |
3 |
25.0 |
2.14 |
6.0 |
3 |
40.0 |
2.14 |
5.5 |
3 |
63.0 |
2.14 |
5.25 |
3 |
100.0 |
2.14 |
4.0 |
3 |
160.0 |
2.14 |
1.75 |
3 |
250.0 |
2.14 |
0.5 |
3 |
400.0 |
2.14 |
0.25 |
3 |
630.0 |
2.14 |
0.0 |
3 |
1000.0 |
2.14 |
0.0 |
3 |
1600.0 |
2.14 |
0.5 |
3 |
2500.0 |
2.14 |
0.0 |
3 |
4000.0 |
2.14 |
0.0 |
3 |
6300.0 |
2.14 |
0.0 |
3 |
10000.0 |
2.14 |
0.25 |
3 |
16000.0 |
2.14 |
1.0 |
Download
|
These EQ is designed for a 15 bands graphical EQ.
Graphic EQ 31 bands
|
Set preamp gain to: -8.9dB.
|
Type |
Freq |
Q |
Gain |
3 |
20.0 |
4.32 |
0.0 |
3 |
25.0 |
4.32 |
6.0 |
3 |
31.0 |
4.32 |
6.0 |
3 |
40.0 |
4.32 |
5.5 |
3 |
50.0 |
4.32 |
5.5 |
3 |
63.0 |
4.32 |
5.25 |
3 |
80.0 |
4.32 |
4.5 |
3 |
100.0 |
4.32 |
4.0 |
3 |
125.0 |
4.32 |
2.75 |
3 |
160.0 |
4.32 |
1.75 |
3 |
200.0 |
4.32 |
1.0 |
3 |
250.0 |
4.32 |
0.5 |
3 |
315.0 |
4.32 |
0.0 |
3 |
400.0 |
4.32 |
0.25 |
3 |
500.0 |
4.32 |
0.0 |
3 |
630.0 |
4.32 |
0.0 |
3 |
800.0 |
4.32 |
-0.25 |
3 |
1000.0 |
4.32 |
0.0 |
3 |
1250.0 |
4.32 |
0.0 |
3 |
1600.0 |
4.32 |
0.25 |
3 |
2000.0 |
4.32 |
-0.25 |
3 |
2500.0 |
4.32 |
0.0 |
3 |
3150.0 |
4.32 |
-0.25 |
3 |
4000.0 |
4.32 |
-0.25 |
3 |
5000.0 |
4.32 |
-0.5 |
3 |
6300.0 |
4.32 |
0.0 |
3 |
8000.0 |
4.32 |
-0.25 |
3 |
10000.0 |
4.32 |
-0.25 |
3 |
12000.0 |
4.32 |
0.5 |
3 |
16000.0 |
4.32 |
0.75 |
3 |
20000.0 |
4.32 |
0.0 |
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
