What we know about the measurement:
- Quality of the measurement data is
medium.
-
Origin of the data is Danley.
-
Format of the data is
a GLL file
.
-
Sensitivity:
-
Sensitivity: 121.3dB (avg. 100Hz-1kHz for 2.83V estimated at 1m).
-
Sensitivity: 101.3dB computed at the measurement distance (10.0m) over the same frequency range.
-
-3dB (resp. -6db) point v.s. reference is at 23.6Hz (resp. 23.6Hz).
-
Reference level is normalised to 0.1dB
computed over the frequency range [300.0Hz,
5000.0Hz].
-
Frequency deviation is 4.3dB over the same frequency range.
- Directivity
-
Horizontal directivity
is (-20.0°, 20.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
-
Vertical directivity
is (-20.0°, 10.0°)
between 1kHz and 10kHz. Angle computed for +/-6dB.
- Tonality (Preference) Score
- Note: The tonality (Preference) score
does not make sense for toursound speakers. Don't give too much credits
to the value.
- Tonality (Preference) Score is 4.09
and would be 5.0 with a
perfect subwoofer.
- Details:
NBD: ON 0.653,
LW 0.688, SP
0.895, PIR
0.754; SM:
SP0.701,
PIR0.52; LFQ
2.807, LFX 23Hz
- Tonality (Preference) Score is 5.34
with an EQ and would be 6.25 with a
perfect subwoofer and the same EQ.
- Details:
NBD: ON 0.576,
LW 0.584, SP
0.774, PIR
0.632; SM:
SP0.876,
PIR0.816; LFQ 2.807, LFX 23Hz
|
AutomaticEQ (IIR)
|
|
Set preamp gain to: -2.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
2.98 |
-6.71 |
| PK |
56.0 |
1.37 |
-2.33 |
| PK |
560.0 |
2.99 |
-1.72 |
| PK |
976.0 |
3.0 |
2.54 |
| PK |
1760.0 |
3.0 |
2.99 |
| PK |
2094.0 |
3.0 |
-1.34 |
| PK |
7834.0 |
0.45 |
-4.2 |
|
Download
|
These EQ optimise the Harman score and is a good start for far field listening like in your living room.
AutomaticEQ
Target v.s. EQ
|
Graphic EQ 15 bands
|
|
Set preamp gain to: -1.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
25.0 |
2.14 |
0.0 |
| PK |
40.0 |
2.14 |
0.0 |
| PK |
63.0 |
2.14 |
0.0 |
| PK |
100.0 |
2.14 |
0.0 |
| PK |
160.0 |
2.14 |
0.25 |
| PK |
250.0 |
2.14 |
0.25 |
| PK |
400.0 |
2.14 |
0.5 |
| PK |
630.0 |
2.14 |
0.5 |
| PK |
1000.0 |
2.14 |
1.0 |
| PK |
1600.0 |
2.14 |
0.75 |
| PK |
2500.0 |
2.14 |
0.5 |
| PK |
4000.0 |
2.14 |
0.5 |
| PK |
6300.0 |
2.14 |
0.25 |
| PK |
10000.0 |
2.14 |
0.5 |
| PK |
16000.0 |
2.14 |
1.25 |
|
Download
|
These EQ is designed for a 15 bands graphical EQ.
|
Graphic EQ 31 bands
|
|
Set preamp gain to: -1.3dB.
|
| Type |
Freq |
Q |
Gain |
| PK |
20.0 |
4.32 |
0.0 |
| PK |
25.0 |
4.32 |
0.0 |
| PK |
31.0 |
4.32 |
0.0 |
| PK |
40.0 |
4.32 |
0.0 |
| PK |
50.0 |
4.32 |
-0.25 |
| PK |
63.0 |
4.32 |
-0.25 |
| PK |
80.0 |
4.32 |
0.0 |
| PK |
100.0 |
4.32 |
0.0 |
| PK |
125.0 |
4.32 |
0.0 |
| PK |
160.0 |
4.32 |
0.0 |
| PK |
200.0 |
4.32 |
0.0 |
| PK |
250.0 |
4.32 |
0.0 |
| PK |
315.0 |
4.32 |
0.0 |
| PK |
400.0 |
4.32 |
0.25 |
| PK |
500.0 |
4.32 |
0.25 |
| PK |
630.0 |
4.32 |
0.25 |
| PK |
800.0 |
4.32 |
0.75 |
| PK |
1000.0 |
4.32 |
1.0 |
| PK |
1250.0 |
4.32 |
0.25 |
| PK |
1600.0 |
4.32 |
0.5 |
| PK |
2000.0 |
4.32 |
0.5 |
| PK |
2500.0 |
4.32 |
0.5 |
| PK |
3150.0 |
4.32 |
0.5 |
| PK |
4000.0 |
4.32 |
0.5 |
| PK |
5000.0 |
4.32 |
0.0 |
| PK |
6300.0 |
4.32 |
0.0 |
| PK |
8000.0 |
4.32 |
0.25 |
| PK |
10000.0 |
4.32 |
0.25 |
| PK |
12000.0 |
4.32 |
0.25 |
| PK |
16000.0 |
4.32 |
1.0 |
| PK |
20000.0 |
4.32 |
0.0 |
|
Download
|
These EQ is designed for a 31 bands graphical EQ.
Comparison betweens various EQs
Improvements made by EQ
|
